Poll Size
Click on the Poll Size button to reveal the X/Y values.
Paper length represents the maximum plotting length.
Paper Width represents the distance between the
farthest two pinch rollers. (Figure 3-4).
Force
Adjusts the blade force between 0 and 250 (Default = 50).
Media Weight
Allows user to select the media weight. There are 2 options: Heavy, and Light (Default).
Offset
Adjusts the blade offset to ensure cutting quality. There are 8 options: 0.000, 0.175
(Default), 0.250, 0.275, 0.300, 0.500, 0.750, and 1.000.
Auto Unroll
Allows user to specify whether the cutter is used in single sheet mode (Auto Unroll Off:
Default) or in roll media mode (Auto Unroll On).
Update Setting
Applies the changed setting onto the cutter by press the Update Setting button.
Vector Smooth
Renders a smoother curve when outputting arcs. (Default: Disable)
