GCC Technologies Expert 52 - Technical Information; Expert 52 Specifications

Expert 52 user manual
Expert 52 Specification
A-1
Model EX-52
Max. Cutting Width
1320mm(51.96in)
Max. Media Width
1470mm(57.87in)
Material Thickness 0.8mm
Max. Cutting Force 250g
Max. Cutting Speed(Diagonal) 400 mm /sec (15.7"/sec)
Mechanical Resolution
0.012 mm
Software Resolution 0.025 mm
Distance Accuracy ±0.254 mm or ±0.1% of move, whichever is greater
Repeatability ±0.1mm
Re-plot Memory 500 Kbyte
Interfaces
USB 2.0 (Full Speed) & RS-
232
Commands HPGL, HPGL/2
Configurable Origin Yes
Control Panel 6 LEDs/10 Keys
Stand Standard
Temperature 15°C~30°C / 60°F~86°F
Operation
Environment
Humidity
25% ~ 75%
 Compatible with Windows 2000/ XP/ Vista/ 7/ 8 and MAC OS X 10.4-10.7.
 The specification and data sheet may vary with different materials used. In order to
obtain the best output quality, please maintain the machine regularly and properly.
 GCC reserves the right to change the specifications at any time without notice
 The above listed specification values are effective only when operated with media
certified by GCC.
Expert 52 Specification
