Expert 52 user manual
General Information 1-3
1.3.2 The Side Views
Object Description
K
AC Power Connector To insert the AC power cord.
L Fuse 3Amp.
M
Power Switch To turn on or off the machine.
N
USB Connector To connect the machine and a computer through a
USB cable.
O
Serial Interface Connector To connect the machine and a computer through a
RS-232 cable.
K
L
M
Figure 1-3
Figure 1-4
N
O
