GCC Technologies i-Craft - Page 25

24
Step 3 Turn the lever clockwise to fix the roller. Then press Feed/Eject
button to load the media to i-Craft
TM
.
Step 4 The edge of the media on the left side should be aligned to the first line
from the left on the front platen.
Pinch roller
Media
First line
of Front
platen
Tips How to align the size you want?
To select a size you want to cut, you may use the guideline marks on the
sticker on the front cover and check which size you want to apply, move
the pinch roller to the corresponding position and lock it in the notch.
