GCC Technologies i-Craft - 6 Appendix; I-Craft TM Specification

61
6. Appendix
6.1 i-Craft
TM
Specification
Model
i-Craft™
Operational Method
Roller-Type
Max. Cutting Width
30.5 cm (12")
Max. Cutting Length
up to 1000mm
Max. Media Loading Width
330mm (13")
Max. Media Cutting Width
32 cm (12.48”)
Number of Pinch Rollers
2
Acceptable Material Thickness
0.8 mm (0.03")
Cutting Force
5~250 g
Max. Cutting Speed
300 mm/sec (12ips)
Over Cut
Yes
Repeat and Copy
Yes
Offset
0~1.0 mm (with an increase of 0.025 mm)
Memory Buffer
32 MB
Interfaces
USB 2.0 (Full Speed), SD card
Mechanical Resolution
0.05 mm
Software Resolution
0.025 mm
Distance Accuracy
±0.254 mm or ±0.1% of move, whichever is greater
Repeatability
±0.1 mm
Control Panel
LCD panel
Diameter of Blade
2.5 mm
Power Supply
AC adapter, 24V DC (1.67A)
Power Consumption
max 40 watts
Automatic-Aligning System
Completely Automatic Contour Cutting System for print to cut
solution
 Compatible with Windows 2000/XP/Vista/7/8 and MAC OS X 10.6-10.10.
 The specification and data sheet may vary with different materials used. In order to obtain the best
output quality, please maintain the machine regularly and properly.
 GCC reserves the right to change the specifications at any time without notice.
 GCC certified material in tracking is Avery MPI 3000.
 The above listed specification values are effective only when operated with media certified by GCC.
