GCC Technologies i-Craft - Cut the Design

32
3.3.6 Cut the Design
Step 1 Click on the “Cutter” button on the toolbar and Cut Settings window will
appear.
Step 2 Click on “Settings…” to open GCC Cutter Settings window
Step 3 Adjust Registration Marks setting under GCC Cutter Settings window if
needed.
*Registration Marks: set the distance between the edge of the material
and the registration marks in Mark Offset; set the size of marks in Mark
Size; set the line thickness of marks in Mark Thickness.
