CHAPTER 4: ACTUAL VALUES A3 RECORDS
345 TRANSFORMER PROTECTION SYSTEM – INSTRUCTION MANUAL 4–11
Each event is saved with event number, date and time, and contains information such as
per-phase current, ground current or sensitive ground current, neutral current, negative
sequence current, ground differential current, per-phase differential and restraint currents.
E5655 TRIP Ph IOC1 Trip OP W2 Ig x
CTg(W2)0.00 x CT 0° Lag
▼
E5655 TRIP Ph IOC1 Trip OPW2 In x
CT(W2)0.00 x CT 0° Lag
▼
E5655 TRIP Ph IOC1 Trip OP W2 Igd x
CT(W2)0.00 x CT
▼
E5655 TRIP Ph IOC1 Trip OP W2 Igr x
CT(W2)0.00 x CT
▼
E5655 TRIP Ph IOC1 Trip OP W2 I_2 x
CT(W1)0.00 x CT
▼
E5655 TRIP Ph IOC1 Trip OP Ph A Diff, x
CT(W1)0.08
▼
E5655 TRIP Ph IOC1 Trip OP Ph BDiff, x
CT(W1)0.00
▼
E5655 TRIP Ph IOC1 Trip OP Ph C Diff, x
CT(W1)0.00
▼
E5655 TRIP Ph IOC1 Trip OP Ph A Rest, x
CT(W1)0.00
▼
E5655 TRIP Ph IOC1 Trip OP Ph B Rest, x
CT(W1)0.00
▼
E5655 TRIP Ph IOC1 Trip OP Ph C Rest, x
CT(W1)0.00
▼
E5655 TRIP Ph IOC1 Trip OP 2nd Harm
Ph A Diff6.2% fo
▼
E5655 TRIP Ph IOC1 Trip OP 2nd Harm
Ph B Diff0.0% fo
▼
E5655 TRIP Ph IOC1 Trip OP 2nd Harm
Ph C Diff0.0% fo
▼
E5655 TRIP Ph IOC1 Trip OP Therm Cap
Ph A1.1% fo
▼
E5655 TRIP Ph IOC1 Trip OP Therm Cap
Ph B0.0%
▼
E5655 TRIP Ph IOC1 Trip OP Therm Cap
Ph C0.0%
