CHAPTER 2: INSTALLATION MECHANICAL INSTALLATION
345 TRANSFORMER PROTECTION SYSTEM – INSTRUCTION MANUAL 2–3
Figure 2-2: 345 dimensions - Non-drawout unit
Product identification
The product identification label is located on the side panel of the 345 . This label indicates
the product model, serial number, and date of manufacture.
Figure 2-3: 345 Product label
NOTE
NOTE:
The pink color text (i.e. Model, Serial Number, Instruction Manual, MFG. Date) is for reference
only. The text can vary.
