CHAPTER 5: QUICK SETUP - FRONT CONTROL PANEL QUICK SETUP SETTINGS
345 TRANSFORMER PROTECTION SYSTEM – INSTRUCTION MANUAL 5–5
RLY1 TRIP W1 BKR
Range: Do not operate, Operate
Default: Do not operate
RLY2 TRIP W2 BKR
Range: Do not operate, Operate
Default: Do not operate
NOTE:
The settings changed using the Quick Setup menu, are available for review and
modification by navigating through S1 RELAY SETUP, S2 SYSTEM SETUP and S3
PROTECTION in the SETPOINTS main menu.
