CHAPTER 13: MODBUS MEMORY MAP
8 SERIES PROTECTIVE RELAY PLATFORM – COMMUNICATIONS GUIDE 13-59
38047 0x1F6E Element Status 148
(Thermal Trip)
0 65535 1 FC151 0 1 Y
38048 0x1F6F Element Status 149
(Thermal Alarm)
0 65535 1 FC151 0 1 Y
38049 0x1F70 Element Status 150
(Current Unbalance
Alarm)
0 65535 1 FC151 0 1 Y
38050 0x1F71 Element Status 151
(Current Unbalance Trip)
0 65535 1 FC151 0 1 Y
38051 0x1F72 Element Status 152
(Mechanical Jam)
0 65535 1 FC151 0 1 Y
38052 0x1F73 Element Status 153
(Undercurrent 1 Alarm)
0 65535 1 FC151 0 1 Y Y
38053 0x1F74 Element Status 154
(Undercurrent 1 Trip)
0 65535 1 FC151 0 1 Y Y
38054 0x1F75 Element Status 155
(Undercurrent 2 Alarm)
0 65535 1 FC151 0 1 Y
38055 0x1F76 Element Status 156
(Undercurrent 2 Trip)
0 65535 1 FC151 0 1 Y
38056 0x1F77 Element Status 157
(Undercurrent 3 Alarm)
0 65535 1 FC151 0 1 Y
38057 0x1F78 Element Status 158
(Undercurrent 3 Trip)
0 65535 1 FC151 0 1 Y
38058 0x1F79 Element Status 159
(Generator Unbalance
Trip)
0 65535 1 FC151 0 1 Y
38059 0x1F7A Element Status 160
(Generator Unbalance
Alarm)
0 65535 1 FC151 0 1 Y
38060 0x1F7B Element Status 161
(Inadvertent Energization)
0 65535 1 FC151 0 1 Y
38061 0x1F7C Element Status 162 (Loss
of Excitation Circle 1)
0 65535 1 FC151 0 1 Y Y
38062 0x1F7D Element Status 163 (Loss
of Excitation Circle 2)
0 65535 1 FC151 0 1 Y Y
38063 0x1F7E Element Status 164 (3rd
Harmonic Neutral UV Trip)
0 65535 1 FC151 0 1 Y
38064 0x1F7F Element Status 165 (3rd
Harmonic Neutral UV
Alarm)
0 65535 1 FC151 0 1 Y
38065 0x1F80 Element Status 166 (3rd
Harmonic Voltage Diff
Trip)
0 65535 1 FC151 0 1 Y
38066 0x1F81 Element Status 167 (3rd
Harmonic Voltage Diff
Alarm)
0 65535 1 FC151 0 1 Y
38067 0x1F82 Element Status 168
(Offline Overcurrent)
0 65535 1 FC151 0 1 Y
38068 0x1F83 Element Status 169
(Overload)
0 65535 1 FC151 0 1 Y Y
38069 0x1F84 Element Status 170 (Short
Circuit)
0 65535 1 FC151 0 1 Y
38070 0x1F85 Element Status 171 (Short
Circuit Speed 2)
0 65535 1 FC151 0 1 Y
38071 0x1F86 Element Status 172
(Ground Fault Alarm)
0 65535 1 FC151 0 1 Y
Modbus
Address
Hex
Address
Description Min Max Step Units Format
Code
Factory
Default
Size in
Words
8
5
0
8
6
9
8
8
9
8
4
5
