13-60 8 SERIES PROTECTIVE RELAY PLATFORM – COMMUNICATIONS GUIDE
CHAPTER 13: MODBUS MEMORY MAP
38072 0x1F87 Element Status 173
(Ground Fault Trip)
0 65535 1 FC151 0 1 Y
38073 0x1F88 Element Status 174
(Acceleration Time)
0 65535 1 FC151 0 1 Y
38074 0x1F89 Element Status 175
(Speed2 Acceleration)
0 65535 1 FC151 0 1 Y
38075 0x1F8A Element Status 176
(Underpower Alarm)
0 65535 1 FC151 0 1 Y
38076 0x1F8B Element Status 177
(Underpower Trip)
0 65535 1 FC151 0 1 Y
38077 0x1F8C Element Status 178
(Transformer Overload)
0 65535 1 FC151 0 1 Y
38078 0x1F8D Element Status 179
(Motor Speed 2 UC Alarm)
0 65535 1 FC151 0 1 Y
38079 0x1F8E Element Status 180
(Motor Speed 2 UC Trip)
0 65535 1 FC151 0 1 Y
38080 0x1F8F Element Status 181
(Phase TOC 1)
0 65535 1 FC151 0 1 Y Y Y Y
38081 0x1F90 Element Status 182
(Phase TOC 2)
0 65535 1 FC151 0 1 Y Y Y
38082 0x1F91 Element Status 183
(Phase TOC 3)
0 65535 1 FC151 0 1 Y Y
38083 0x1F92 Element Status 184
(Phase TOC 4)
0 65535 1 FC151 0 1 Y
38084 0x1F93 Element Status 185
(Phase TOC 5)
0 65535 1 FC151 0 1 Y
38085 0x1F94 Element Status 186
(Phase TOC 6)
0 65535 1 FC151 0 1 Y
38086 0x1F95 Element Status 187
(Phase TOC 7)
0 65535 1 FC151 0 1 Y
38087 0x1F96 Element Status 188
(Phase TOC 8)
0 65535 1 FC151 0 1 Y
38090 0x1F99 Element Status 191
(Phase IOC 1)
0 65535 1 FC151 0 1 Y Y Y Y
38091 0x1F9A Element Status 192
(Phase IOC 2)
0 65535 1 FC151 0 1 Y Y Y Y
38092 0x1F9B Element Status 193
(Phase IOC 3)
0 65535 1 FC151 0 1 Y Y Y
38093 0x1F9C Element Status 194
(Phase IOC 4)
0 65535 1 FC151 0 1 Y Y Y
38094 0x1F9D Element Status 195
(Phase IOC 5)
0 65535 1 FC151 0 1 Y Y Y
38095 0x1F9E Element Status 196
(Phase IOC 6)
0 65535 1 FC151 0 1 Y Y Y
38096 0x1F9F Element Status 197
(Phase IOC 7)
0 65535 1 FC151 0 1 Y Y
38097 0x1FA0 Element Status 198
(Phase IOC 8)
0 65535 1 FC151 0 1 Y Y
38098 0x1FA1 Element Status 199
(Phase IOC 9)
0 65535 1 FC151 0 1 Y
38099 0x1FA2 Element Status 200
(Phase IOC 10)
0 65535 1 FC151 0 1 Y
38100 0x1FA3 Element Status 201
(Phase IOC 11)
0 65535 1 FC151 0 1 Y
38101 0x1FA4 Element Status 202
(Phase IOC 12)
0 65535 1 FC151 0 1 Y
