CHAPTER 13: MODBUS MEMORY MAP
8 SERIES PROTECTIVE RELAY PLATFORM – COMMUNICATIONS GUIDE 13-61
38102 0x1FA5 Element Status 203
(Phase IOC 13)
0 65535 1 FC151 0 1 Y
38103 0x1FA6 Element Status 204
(Phase IOC 14)
0 65535 1 FC151 0 1 Y
38104 0x1FA7 Element Status 205
(Phase IOC 15)
0 65535 1 FC151 0 1 Y
38105 0x1FA8 Element Status 206
(Phase IOC 16)
0 65535 1 FC151 0 1 Y
38106 0x1FA9 Element Status 207
(Phase IOC 17)
0 65535 1 FC151 0 1 Y
38107 0x1FAA Element Status 208
(Phase IOC 18)
0 65535 1 FC151 0 1 Y
38108 0x1FAB Element Status 209
(Phase IOC 19)
0 65535 1 FC151 0 1 Y
38109 0x1FAC Element Status 210
(Phase IOC 20)
0 65535 1 FC151 0 1 Y
38110 0x1FAD Element Status 211
(Phase Directional OC 1)
0 65535 1 FC151 0 1 Y Y Y Y
38111 0x1FAE Element Status 212
(Phase Directional OC 2)
0 65535 1 FC151 0 1 Y
38112 0x1FAF Element Status 213
(Phase Directional OC 3)
0 65535 1 FC151 0 1 Y
38113 0x1FB0 Element Status 214
(Phase Directional OC 4)
0 65535 1 FC151 0 1 Y
38118 0x1FB5 Element Status 219
(Neutral TOC 1)
0 65535 1 FC151 0 1 Y Y Y Y
38119 0x1FB6 Element Status 220
(Neutral TOC 2)
0 65535 1 FC151 0 1 Y Y Y
38120 0x1FB7 Element Status 221 (Ntrl
TOC 3)
0 65535 1 FC151 0 1 Y Y
38121 0x1FB8 Element Status 222 (Ntrl
TOC 4)
0 65535 1 FC151 0 1 Y
38122 0x1FB9 Element Status 223 (Ntrl
TOC 5)
0 65535 1 FC151 0 1 Y
38123 0x1FBA Element Status 224 (Ntrl
TOC 6)
0 65535 1 FC151 0 1 Y
38124 0x1FBB Element Status 225 (Ntrl
TOC 7)
0 65535 1 FC151 0 1 Y
38125 0x1FBC Element Status 226 (Ntrl
TOC 8)
0 65535 1 FC151 0 1 Y
38128 0x1FBF Element Status 229
(Neutral IOC 1)
0 65535 1 FC151 0 1 Y Y Y Y
38129 0x1FC0 Element Status 230
(Neutral IOC 2)
0 65535 1 FC151 0 1 Y Y Y Y
38130 0x1FC1 Element Status 231 (Ntrl
IOC 3)
0 65535 1 FC151 0 1 Y Y Y
38131 0x1FC2 Element Status 232 (Ntrl
IOC 4)
0 65535 1 FC151 0 1 Y Y
38132 0x1FC3 Element Status 233 (Ntrl
IOC 5)
0 65535 1 FC151 0 1 Y Y
38133 0x1FC4 Element Status 234 (Ntrl
IOC 6)
0 65535 1 FC151 0 1 Y Y
38134 0x1FC5 Element Status 235 (Ntrl
IOC 7)
0 65535 1 FC151 0 1 Y
38135 0x1FC6 Element Status 236 (Ntrl
IOC 8)
0 65535 1 FC151 0 1 Y
