GE Multilin 869 - Page 184

13-62 8 SERIES PROTECTIVE RELAY PLATFORM – COMMUNICATIONS GUIDE
CHAPTER 13: MODBUS MEMORY MAP
38136 0x1FC7 Element Status 237 (Ntrl
IOC 9)
0 65535 1 FC151 0 1 Y
38137 0x1FC8 Element Status 238 (Ntrl
IOC 10)
0 65535 1 FC151 0 1 Y
38138 0x1FC9 Element Status 239 (Ntrl
IOC 11)
0 65535 1 FC151 0 1 Y
38139 0x1FCA Element Status 240 (Ntrl
IOC 12)
0 65535 1 FC151 0 1 Y
38140 0x1FCB Element Status 241 (Ntrl
IOC 13)
0 65535 1 FC151 0 1 Y
38141 0x1FCC Element Status 242 (Ntrl
IOC 14)
0 65535 1 FC151 0 1 Y
38142 0x1FCD Element Status 243 (Ntrl
IOC 15)
0 65535 1 FC151 0 1 Y
38143 0x1FCE Element Status 244 (Ntrl
IOC 16)
0 65535 1 FC151 0 1 Y
38148 0x1FD3 Element Status 249
(Neutral Directional OC 1)
0 65535 1 FC151 0 1 Y Y Y Y
38149 0x1FD4 Element Status 250
(Neutral Directional OC 2)
0 65535 1 FC151 0 1 Y
38150 0x1FD5 Element Status 251
(Neutral Directional OC 3)
0 65535 1 FC151 0 1 Y
38151 0x1FD6 Element Status 252
(Neutral Directional OC 4)
0 65535 1 FC151 0 1 Y
38156 0x1FDB Element Status 257
(Ground TOC 1)
0 65535 1 FC151 0 1 Y Y Y Y
38157 0x1FDC Element Status 258
(Ground TOC 2)
0 65535 1 FC151 0 1 Y Y Y
38158 0x1FDD Element Status 259
(Ground TOC 3)
0 65535 1 FC151 0 1 Y Y
38159 0x1FDE Element Status 260
(Ground TOC 4)
0 65535 1 FC151 0 1 Y
38160 0x1FDF Element Status 261
(Ground TOC 5)
0 65535 1 FC151 0 1 Y
38161 0x1FE0 Element Status 262
(Ground TOC 6)
0 65535 1 FC151 0 1 Y
38164 0x1FE3 Element Status 265
(Ground IOC 1)
0 65535 1 FC151 0 1 Y Y Y Y
38165 0x1FE4 Element Status 266
(Ground IOC 2)
0 65535 1 FC151 0 1 Y Y Y
38166 0x1FE5 Element Status 267
(Ground IOC 3)
0 65535 1 FC151 0 1 Y Y
38167 0x1FE6 Element Status 268
(Ground IOC 4)
0 65535 1 FC151 0 1 Y Y
38168 0x1FE7 Element Status 269 (Gnd
IOC 5)
0 65535 1 FC151 0 1 Y Y
38169 0x1FE8 Element Status 270 (Gnd
IOC 6)
0 65535 1 FC151 0 1 Y Y
38170 0x1FE9 Element Status 271 (GND
IOC 7)
0 65535 1 FC151 0 1 Y
38171 0x1FEA Element Status 272 (GND
IOC 8)
0 65535 1 FC151 0 1 Y
38172 0x1FEB Element Status 273 (GND
IOC 9)
0 65535 1 FC151 0 1 Y
38173 0x1FEC Element Status 274 (GND
IOC 10)
0 65535 1 FC151 0 1 Y
Modbus
Address
Hex
Address
Description Min Max Step Units Format
Code
Factory
Default
Size in
Words
8
5
0
8
6
9
8
8
9
8
4
5
