GE Multilin 869 - Page 185

CHAPTER 13: MODBUS MEMORY MAP
8 SERIES PROTECTIVE RELAY PLATFORM – COMMUNICATIONS GUIDE 13-63
38174 0x1FED Element Status 275 (GND
IOC 11)
0 65535 1 FC151 0 1 Y
38175 0x1FEE Element Status 276 (GND
IOC 12)
0 65535 1 FC151 0 1 Y
38180 0x1FF3 Element Status 281
(Ground Directional OC 1)
0 65535 1 FC151 0 1 Y Y Y
38181 0x1FF4 Element Status 282
(Ground Directional OC 2)
0 65535 1 FC151 0 1 Y
38184 0x1FF7 Element Status 285
(Sensitive Ground TOC 1)
0 65535 1 FC151 0 1 Y Y
38185 0x1FF8 Element Status 286
(Sensitive Ground TOC 2)
0 65535 1 FC151 0 1 Y
38188 0x1FFB Element Status 289
(Sensitive Ground IOC 1)
0 65535 1 FC151 0 1 Y Y
38189 0x1FFC Element Status 290
(Sensitive Ground IOC 2)
0 65535 1 FC151 0 1 Y
38190 0x1FFD Element Status 291
(Sensitive Ground IOC 3)
0 65535 1 FC151 0 1 Y
38191 0x1FFE Element Status 292
(Sensitive Ground IOC 4)
0 65535 1 FC151 0 1 Y
38196 0x2003 Element Status 297
(Sensitive Ground
Directional OC 1)
0 65535 1 FC151 0 1 Y Y
38200 0x2007 Element Status 301
(Restricted Ground Fault
1)
0 65535 1 FC151 0 1 Y Y Y
38201 0x2008 Element Status 302
(Restricted Ground Fault
2)
0 65535 1 FC151 0 1 Y Y
38202 0x2009 Element Status 303
(Restricted Ground Fault
3)
0 65535 1 FC151 0 1 Y Y
38206 0x200D Element Status 307
(Switch On To Fault 1)
0 65535 1 FC151 0 1 Y
38207 0x200E Element Status 308
(Switch On To Fault 2)
0 65535 1 FC151 0 1 Y
38208 0x200F Element Status 309
(Switch On To Fault 3)
0 65535 1 FC151 0 1 Y
38209 0x2010 Element Status 310
(Switch On To Fault 4)
0 65535 1 FC151 0 1 Y
38210 0x2011 Element Status 311
(Switch On To Fault 5)
0 65535 1 FC151 0 1 Y
38211 0x2012 Element Status 312
(Switch On To Fault 6)
0 65535 1 FC151 0 1 Y
38212 0x2013 Element Status 313
(Negative Sequence TOC
1)
0 65535 1 FC151 0 1 Y Y
38213 0x2014 Element Status 314
(Negative Sequence TOC
2)
0 65535 1 FC151 0 1 Y Y
38214 0x2015 Element Status 315 (Neg
Seq TOC 3)
0 65535 1 FC151 0 1 Y Y
38215 0x2016 Element Status 316 (Neg
Seq TOC 4)
0 65535 1 FC151 0 1 Y
38216 0x2017 Element Status 317 (Neg
Seq TOC 5)
0 65535 1 FC151 0 1 Y
Modbus
Address
Hex
Address
Description Min Max Step Units Format
Code
Factory
Default
Size in
Words
8
5
0
8
6
9
8
8
9
8
4
5
