13-64 8 SERIES PROTECTIVE RELAY PLATFORM – COMMUNICATIONS GUIDE
CHAPTER 13: MODBUS MEMORY MAP
38217 0x2018 Element Status 318 (Neg
Seq TOC 6)
0 65535 1 FC151 0 1 Y
38218 0x2019 Element Status 319 (Neg
Seq TOC 7)
0 65535 1 FC151 0 1 Y
38219 0x201A Element Status 320 (Neg
Seq TOC 8)
0 65535 1 FC151 0 1 Y
38222 0x201D Element Status 323
(Negative Sequence IOC
1)
0 65535 1 FC151 0 1 Y Y Y Y
38223 0x201E Element Status 324
(Negative Sequence IOC
2)
0 65535 1 FC151 0 1 Y Y Y
38224 0x201F Element Status 325 (Neg
Seq IOC 3)
0 65535 1 FC151 0 1 Y Y Y
38225 0x2020 Element Status 326 (Neg
Seq IOC 4)
0 65535 1 FC151 0 1 Y
38226 0x2021 Element Status 327 (Neg
Seq IOC 5)
0 65535 1 FC151 0 1 Y
38227 0x2022 Element Status 328 (Neg
Seq IOC 6)
0 65535 1 FC151 0 1 Y
38228 0x2023 Element Status 329 (Neg
Seq IOC 7)
0 65535 1 FC151 0 1 Y
38229 0x2024 Element Status 330 (Neg
Seq IOC 8)
0 65535 1 FC151 0 1 Y
38230 0x2025 Element Status 331 (Neg
Seq IOC 9)
0 65535 1 FC151 0 1 Y
38231 0x2026 Element Status 332 (Neg
Seq IOC 10)
0 65535 1 FC151 0 1 Y
38232 0x2027 Element Status 333 (Neg
Seq IOC 11)
0 65535 1 FC151 0 1 Y
38233 0x2028 Element Status 334 (Neg
Seq IOC 12)
0 65535 1 FC151 0 1 Y
38234 0x2029 Element Status 335 (Neg
Seq IOC 13)
0 65535 1 FC151 0 1 Y
38235 0x202A Element Status 336 (Neg
Seq IOC 14)
0 65535 1 FC151 0 1 Y
38236 0x202B Element Status 337 (Neg
Seq IOC 15)
0 65535 1 FC151 0 1 Y
38237 0x202C Element Status 338 (Neg
Seq IOC 16)
0 65535 1 FC151 0 1 Y
38242 0x2031 Element Status 343
(Negative Sequence Dir
OC 1)
0 65535 1 FC151 0 1 Y Y
38243 0x2032 Element Status 344
(Negative Sequence Dir
OC 2)
0 65535 1 FC151 0 1 Y
38246 0x2035 Element Status 347
(Broken Conductor 1)
0 65535 1 FC151 0 1 Y
38247 0x2036 Element Status 348
(Broken Conductor 2)
0 65535 1 FC151 0 1 Y
38248 0x2037 Element Status 349
(Broken Conductor 3)
0 65535 1 FC151 0 1 Y
38250 0x2039 Element Status 351 (Load
Encroachment 1)
0 65535 1 FC151 0 1 Y
38251 0x203A Element Status 352 (Load
Encroachment 2)
0 65535 1 FC151 0 1 Y
Modbus
Address
Hex
Address
Description Min Max Step Units Format
Code
Factory
Default
Size in
Words
8
5
0
8
6
9
8
8
9
8
4
5
