CHAPTER 13: MODBUS MEMORY MAP
8 SERIES PROTECTIVE RELAY PLATFORM – COMMUNICATIONS GUIDE 13-65
38254 0x203D Element Status 355
(Thermal Overload 1)
0 65535 1 FC151 0 1 Y
38255 0x203E Element Status 356
(Thermal Overload 1 Alrm)
0 65535 1 FC151 0 1 Y
38256 0x203F Element Status 357
(Thermal Overload 2)
0 65535 1 FC151 0 1 Y
38257 0x2040 Element Status 358
(Thermal Overload 2 Alrm)
0 65535 1 FC151 0 1 Y
38262 0x2045 Element Status 363
(Phase Reversal)
0 65535 1 FC151 0 1 Y Y
38263 0x2046 Element Status 364
(Phase UV 1)
0 65535 1 FC151 0 1 Y Y Y Y
38264 0x2047 Element Status 365
(Phase UV 2)
0 65535 1 FC151 0 1 Y Y Y Y
38265 0x2048 Element Status 366
(Phase UV 3)
0 65535 1 FC151 0 1 Y
38266 0x2049 Element Status 367
(Phase UV 4)
0 65535 1 FC151 0 1 Y
38267 0x204A Element Status 368
(Phase UV 5)
0 65535 1 FC151 0 1 Y
38268 0x204B Element Status 369
(Phase UV 6)
0 65535 1 FC151 0 1 Y
38269 0x204C Element Status 370
(Phase UV 7)
0 65535 1 FC151 0 1 Y
38270 0x204D Element Status 371
(Phase UV 8)
0 65535 1 FC151 0 1 Y
38275 0x2052 Element Status 376
(Timed UV 1)
0 65535 1 FC151 0 1 Y
38276 0x2053 Element Status 377
(Timed UV Curve Count 1)
0 65535 1 FC151 0 1 Y
38277 0x2054 Element Status 378
(Timed UV 2)
0 65535 1 FC151 0 1 Y
38278 0x2055 Element Status 379
(Timed UV Curve Count 2)
0 65535 1 FC151 0 1 Y
38279 0x2056 Element Status 380
(Timed UV 3)
0 65535 1 FC151 0 1 Y
38280 0x2057 Element Status 381
(Timed UV Curve Count 3)
0 65535 1 FC151 0 1 Y
38281 0x2058 Element Status 382
(Timed UV 4)
0 65535 1 FC151 0 1 Y
38282 0x2059 Element Status 383
(Timed UV Curve Count 4)
0 65535 1 FC151 0 1 Y
38291 0x2062 Element Status 392 (UV
ReactivePwr 1)
0 65535 1 FC151 0 1 Y
38292 0x2063 Element Status 393 (UV
ReactivePwr 2)
0 65535 1 FC151 0 1 Y
38293 0x2064 Element Status 394 (UV
ReactivePwr 3)
0 65535 1 FC151 0 1 Y
38294 0x2065 Element Status 395 (UV
ReactivePwr 4)
0 65535 1 FC151 0 1 Y
38295 0x2066 Element Status 396 (UV
ReactivePwr 5)
0 65535 1 FC151 0 1 Y
38296 0x2067 Element Status 397 (UV
ReactivePwr 6)
0 65535 1 FC151 0 1 Y
38299 0x206A Element Status 400
(Auxiliary UV 1)
0 65535 1 FC151 0 1 Y Y Y Y
Modbus
Address
Hex
Address
Description Min Max Step Units Format
Code
Factory
Default
Size in
Words
8
5
0
8
6
9
8
8
9
8
4
5
