GE Multilin 869 - Page 188

13-66 8 SERIES PROTECTIVE RELAY PLATFORM – COMMUNICATIONS GUIDE
CHAPTER 13: MODBUS MEMORY MAP
38300 0x206B Element Status 401
(Auxiliary UV 2)
0 65535 1 FC151 0 1 Y Y Y Y
38301 0x206C Element Status 402
(Auxiliary UV 3)
0 65535 1 FC151 0 1 Y
38302 0x206D Element Status 403
(Auxiliary UV 4)
0 65535 1 FC151 0 1 Y
38305 0x2070 Element Status 406
(Phase OV 1)
0 65535 1 FC151 0 1 Y Y Y Y
38306 0x2071 Element Status 407
(Phase OV 2)
0 65535 1 FC151 0 1 Y Y Y Y
38307 0x2072 Element Status 408
(Phase OV 3)
0 65535 1 FC151 0 1 Y
38308 0x2073 Element Status 409
(Phase OV 4)
0 65535 1 FC151 0 1 Y
38313 0x2078 Element Status 414
(Auxiliary OV 1)
0 65535 1 FC151 0 1 Y Y Y Y
38314 0x2079 Element Status 415 (Aux
OV 2)
0 65535 1 FC151 0 1 Y Y
38315 0x207A Element Status 416 (Aux
OV 3)
0 65535 1 FC151 0 1 Y
38316 0x207B Element Status 417 (Aux
OV 4)
0 65535 1 FC151 0 1 Y
38321 0x2080 Element Status 422
(Neutral OV 1)
0 65535 1 FC151 0 1 Y Y Y Y
38322 0x2081 Element Status 423
(Neutral OV 2)
0 65535 1 FC151 0 1 Y
38323 0x2082 Element Status 424
(Neutral OV 3)
0 65535 1 FC151 0 1 Y
38324 0x2083 Element Status 425
(Neutral OV 4)
0 65535 1 FC151 0 1 Y
38329 0x2088 Element Status 430
(Negative Sequence OV 1)
0 65535 1 FC151 0 1 Y Y Y Y
38330 0x2089 Element Status 431
(Negative Sequence OV 2)
0 65535 1 FC151 0 1 Y Y
38331 0x208A Element Status 432
(Negative Sequence OV 3)
0 65535 1 FC151 0 1 Y
38332 0x208B Element Status 433
(Negative Sequence OV 4)
0 65535 1 FC151 0 1 Y
38335 0x208E Element Status 436 (Volts
per Hertz 1)
0 65535 1 FC151 0 1 Y Y Y
38336 0x208F Element Status 437 (Volts
per Hertz 2)
0 65535 1 FC151 0 1 Y Y
38337 0x2090 Element Status 438 (Out-
of-Step)
0 65535 1 FC151 0 1 Y Y
38338 0x2091 Element Status 439
(Neutral Admittance 1)
0 65535 1 FC151 0 1 Y
38339 0x2092 Element Status 440
(Neutral Admittance 2)
0 65535 1 FC151 0 1 Y
38340 0x2093 Element Status 441
(Neutral Admittance 3)
0 65535 1 FC151 0 1 Y
38344 0x2097 Element Status 445 (Dir
Power 1)
0 65535 1 FC151 0 1 Y Y Y Y
38345 0x2098 Element Status 446 (Dir
Power 2)
0 65535 1 FC151 0 1 Y Y Y Y
38346 0x2099 Element Status 447 (Dir
Power 3)
0 65535 1 FC151 0 1 Y
Modbus
Address
Hex
Address
Description Min Max Step Units Format
Code
Factory
Default
Size in
Words
8
5
0
8
6
9
8
8
9
8
4
5
