CHAPTER 13: MODBUS MEMORY MAP
8 SERIES PROTECTIVE RELAY PLATFORM – COMMUNICATIONS GUIDE 13-67
38347 0x209A Element Status 448 (Dir
Power 4)
0 65535 1 FC151 0 1 Y
38352 0x209F Element Status 453
(Wattmetric Ground Fault
1)
0 65535 1 FC151 0 1 Y
38353 0x20A0 Element Status 454
(Wattmetric Ground Fault
2)
0 65535 1 FC151 0 1 Y
38354 0x20A1 Element Status 455
(Wattmetric Ground Fault
3)
0 65535 1 FC151 0 1 Y
38355 0x20A2 Element Status 456
(Wattmetric Ground Fault
4)
0 65535 1 FC151 0 1 Y
38360 0x20A7 Element Status 461
(Reactive Power Trip)
0 65535 1 FC151 0 1 Y Y
38361 0x20A8 Element Status 462
(Reactive Power Alarm)
0 65535 1 FC151 0 1 Y Y
38362 0x20A9 Element Status 463
(Underfrequency 1)
0 65535 1 FC151 0 1 Y Y Y Y
38363 0x20AA Element Status 464
(Underfrequency 2)
0 65535 1 FC151 0 1 Y Y Y Y
38364 0x20AB Element Status 465
(Underfrequency 3)
0 65535 1 FC151 0 1 Y Y Y Y
38365 0x20AC Element Status 466
(Underfrequency 4)
0 65535 1 FC151 0 1 Y Y Y Y
38366 0x20AD Element Status 467
(Underfrequency 5)
0 65535 1 FC151 0 1 Y
38367 0x20AE Element Status 468
(Underfrequency 6)
0 65535 1 FC151 0 1 Y
38368 0x20AF Element Status 469
(Underfrequency 7)
0 65535 1 FC151 0 1 Y
38369 0x20B0 Element Status 470
(Underfrequency 8)
0 65535 1 FC151 0 1 Y
38370 0x20B1 Element Status 471
(Underfrequency 9)
0 65535 1 FC151 0 1 Y
38371 0x20B2 Element Status 472
(Underfrequency 10)
0 65535 1 FC151 0 1 Y
38372 0x20B3 Element Status 473
(Underfrequency 11)
0 65535 1 FC151 0 1 Y
38373 0x20B4 Element Status 474
(Underfrequency 12)
0 65535 1 FC151 0 1 Y
38380 0x20BB Element Status 481
(Overfrequency 1)
0 65535 1 FC151 0 1 Y Y Y Y
38381 0x20BC Element Status 482
(Overfrequency 2)
0 65535 1 FC151 0 1 Y Y Y Y
38382 0x20BD Element Status 483
(Overfrequency 3)
0 65535 1 FC151 0 1 Y
38383 0x20BE Element Status 484
(Overfrequency 4)
0 65535 1 FC151 0 1 Y
38384 0x20BF Element Status 485
(Overfrequency 5)
0 65535 1 FC151 0 1 Y
38385 0x20C0 Element Status 486
(Overfrequency 6)
0 65535 1 FC151 0 1 Y
38386 0x20C1 Element Status 487
(Overfrequency 7)
0 65535 1 FC151 0 1 Y
