CHAPTER 13: MODBUS MEMORY MAP
8 SERIES PROTECTIVE RELAY PLATFORM – COMMUNICATIONS GUIDE 13-199
64262 0x5EC5 Speed2 Switch 2-1 Delay 0 60000 1 s F2 500 1 Y
64263 0x5EC6 Speed2 CT Primary 1 12000 1 A F0 500 1 Y
64264 0x5EC7 Speed2 Motor FLA 1 5000 1 A F0 100 1 Y
64265 0x5EC8 Number of Poles 2 64 2 F0 2 1 Y
64266 0x5EC9 Motor Horsepower 100 200000 1 Hp F10 4000 2 Y
64269 0x5ECC Max. Acceleration Time 100 18000 1 s F2 1000 1 Y
64270 0x5ECD Speed2 Max. Accel Time 100 18000 1 s F2 1000 1 Y
VFD
64290 0x5EE1 Function 0 1 1 FC126 0 1 Y
64291 0x5EE2 Bypass Switch 0 0xC6CD00 1 FC142 0 2 Y
64293 0x5EE4 Starting Frequency 30 720 1 Hz F1 100 1 Y
Motor Preset Values
64310 0x5EF5 Motor Running Hours 0 100000 1 hrs F10 0 2 Y
64312 0x5EF7 Pos Watt Hours 0 4294967295 1 MWh F13 0 2 Y
64314 0x5EF9 Neg Watt Hours 0 4294967295 1 MWh F13 0 2 Y
64316 0x5EFB Pos Var Hours 0 4294967295 1 Mvarh F13 0 2 Y
64318 0x5EFD Neg Var Hours 0 4294967295 1 Mvarh F13 0 2 Y
Generator System Settings
64340 0x5F13 Rated MVA 0 2000000 1 MVA F13 50000 2 Y
64342 0x5F15 Rated Power Factor 0 99 1 F2 85 1 Y
64343 0x5F16 Rated Phase-Phase
Voltage
0 300000 1 V F11 138000 2 Y
64345 0x5F18 Average Calc. Period 1 90 1 min F0 15 1 Y
Transformer General Setup
64360 0x5F27 Phase Compensation 0 1 1 FC369 0 1 Y
64361 0x5F28 Load Loss at Rated Load 1 20000000 1 kW F13 100000 2 Y
64363 0x5F2A Rated Wndg Temp Rise 0 4 1 FC367 1 1 Y
64364 0x5F2B No Load loss 1 20000000 1 kW F13 10000 2 Y
64366 0x5F2D Type of Cooling 0 6 1 FC368 0 1 Y
64367 0x5F2E Top Oil Rise over Ambient 1 200 1 °C F0 35 1 Y
64368 0x5F2F Xfmr Thermal Capacity 0 20000 1 kWh/°C F2 100 1 Y
64369 0x5F30 Wndg Thermal Time
Constant
25 1500 1 min F2 200 1 Y
64370 0x5F31 Energization Winding
Source
1 5 1 FC102A 1 1 Y
64371 0x5F32 Year of Manufacture 1950 2100 1 F0 1950 1 Y
Transformer Winding 1
64391 0x5F46 Rated MVA 1 2000000 1 MVA F13 5000 2 Y Y
64393 0x5F48 Nominal Ph-Ph Voltage 1 1000000 1 kV F13 13800 2 Y Y
64395 0x5F4A Connection 0 2 1 FC375 0 1 Y Y
64397 0x5F4C Grounding 0 1 1 FC376 0 1 Y Y
64398 0x5F4D Wndg Resistance (3-ph) 1 1000000 1 ohms F14 100000 2 Y Y
Transformer Winding 2
64407 0x5F56 Rated MVA 1 2000000 1 MVA F13 5000 2 Y Y
64409 0x5F58 Nominal Ph-Ph Voltage 1 1000000 1 kV F13 13800 2 Y Y
64411 0x5F5A Connection 0 2 1 FC375 0 1 Y Y
Modbus
Address
Hex
Address
Description Min Max Step Units Format
Code
Factory
Default
Size in
Words
8
5
0
8
6
9
8
8
9
8
4
5
To Next Page
