13-200 8 SERIES PROTECTIVE RELAY PLATFORM – COMMUNICATIONS GUIDE
CHAPTER 13: MODBUS MEMORY MAP
64412 0x5F5B Angle With Respect To W1 0 11 1 FC377 0 1 Y Y
64413 0x5F5C Grounding 0 1 1 FC376 0 1 Y Y
64414 0x5F5D Wndg Resistance (3-ph) 1 1000000 1 ohms F14 100000 2 Y Y
Transformer Winding 3
64423 0x5F66 Rated MVA 1 2000000 1 MVA F13 5000 2 Y
64425 0x5F68 Nominal Ph-Ph Voltage 1 1000000 1 kV F13 13800 2 Y
64427 0x5F6A Connection 0 2 1 FC375 0 1 Y
64428 0x5F6B Angle With Respect To W1 0 11 1 FC377 0 1 Y
64429 0x5F6C Grounding 0 1 1 FC376 0 1 Y
64430 0x5F6D Wndg Resistance (3-ph) 1 1000000 1 ohms F14 100000 2 Y
Xfmr Status Detection
64460 0x5F8B Sensing by Breakers
Open
0 1 1 FC126 0 1 Y
64461 0x5F8C All Breakers Open 0 0xC6CD00 1 FC142 0 2 Y
64463 0x5F8E Sensing by Voltage 0 0x22 1 FC103E 0 1 Y
64464 0x5F8F Minimum Voltage 50 99 1 x VT F2 85 1 Y
64465 0x5F90 Current Supervision 0 1 1 FC126 0 1 Y
64466 0x5F91 Minimum Current 20 500 1 x CT F3 50 1 Y
Thermal Inputs
64480 0x5F9F Winding Currents 1 5 1 FC102A 1 1 Y
64481 0x5FA0 Ambient Temperature 0 30 1 FC370 0 1 Y
64482 0x5FA1 Ambient Temp Avg - Jan -60 60 1 °C F20 -20 1 Y
64483 0x5FA2 Ambient Temp Avg - Feb -60 60 1 °C F20 -20 1 Y
64484 0x5FA3 Ambient Temp Avg - Mar -60 60 1 °C F20 -10 1 Y
64485 0x5FA4 Ambient Temp Avg - Apr -60 60 1 °C F20 10 1 Y
64486 0x5FA5 Ambient Temp Avg - May -60 60 1 °C F20 20 1 Y
64487 0x5FA6 Ambient Temp Avg - Jun -60 60 1 °C F20 30 1 Y
64488 0x5FA7 Ambient Temp Avg - Jul -60 60 1 °C F20 30 1 Y
64489 0x5FA8 Ambient Temp Avg - Aug -60 60 1 °C F20 30 1 Y
64490 0x5FA9 Ambient Temp Avg - Sep -60 60 1 °C F20 20 1 Y
64491 0x5FAA Ambient Temp Avg - Oct -60 60 1 °C F20 10 1 Y
64492 0x5FAB Ambient Temp Avg - Nov -60 60 1 °C F20 10 1 Y
64493 0x5FAC Ambient Temp Avg - Dec -60 60 1 °C F20 -10 1 Y
64494 0x5FAD Top Oil Temperature 0 30 1 FC371 0 1 Y
Tap Changer
64510 0x5FBD Tap Position Detection 0 1 1 FC126 0 1 Y
64511 0x5FBE TC Winding Currents 0 4 1 FC102B 0 1 Y
64512 0x5FBF Tap Detection Input 0 2 1 FC372 0 1 Y
64513 0x5FC0 Min Tap -19 35 1 F20 -16 1 Y
64514 0x5FC1 Neutral Tap -17 37 1 F20 0 1 Y
64515 0x5FC2 Max Tap 0 39 1 F0 16 1 Y
64516 0x5FC3 Min Tap Voltage 1 2000000 1 kV F12 6100 2 Y
64518 0x5FC5 Voltage Increment per
Tap
1 2000 1 kV F2 50 1 Y
64519 0x5FC6 Ohms at Min Tap 0 5100 1 ohms F0 33 1 Y
64520 0x5FC7 Ohms at Max Tap 0 5100 1 ohms F0 1089 1 Y
Modbus
Address
Hex
Address
Description Min Max Step Units Format
Code
Factory
Default
Size in
Words
8
5
0
8
6
9
8
8
9
8
4
5
