CHAPTER B: IEC 61850 IMPLEMENTATION DETAILS MICS
8 SERIES PROTECTIVE RELAY PLATFORM – COMMUNICATIONS GUIDE B-15
2.2.12 PDOP (Directional Overpower)
PDOP: Directional overpower
2.2.13 PMRI (Start inhibit)
PMRI: Start Inhibit (869)
2.2.14 PDUP (Directional Underpower)
tripPDUP: Trip underpower (869)
almPDUP: Alarm underpower (869)
SeqShtdnPDUP: Sequential Shutdown (889)
Health ENS_1 Health M
NamPlt LPL_1 Name plate M
Status Information
Str ACD_2 Start M
Op ACT_2 Operate O
PDOP class
Attribute Name Attr. Type Explanation M/O Notes
PDOP Directional Overpower
Data
Common Logical Node Information
Mod ENC_0 Mode M
Beh ENS_0 Behavior M
Health ENS_1 Health M
NamPlt LPL_1 Name plate M
Status Information
Str ACD_2 Start M
Op ACT_2 Operate M
PMRI class
Attribute Name Attr. Type Explanation M/O Notes
PMRI Start inhibit
Data
Common Logical Node Information
Mod ENC_0 Mode M
Beh ENS_0 Behavior M
Health ENS_1 Health M
NamPlt LPL_1 Name plate M
Status Information
Strlnh SPS_0 Start inhibited O
PDUP class
Attribute Name Attr. Type Explanation M/O Notes
TripPDUP/
almPDUP/
SeqShtdnPDUP
Directional Underpower
Data
