B-16 8 SERIES PROTECTIVE RELAY PLATFORM – COMMUNICATIONS GUIDE
MICS CHAPTER B: IEC 61850 IMPLEMENTATION DETAILS
RctPwrTripPDUP: Reactive power trip (869, 889)
RctPwrAlmPDUP: Reactive power alarm (869, 889)
2.2.15 PTUC (Undercurrent)
PTUC: Undercurrent (869)
Common Logical Node Information
Mod ENC_0 Mode M
Beh ENS_0 Behavior M
Health ENS_1 Health M
NamPlt LPL_1 Name plate M
Status Information
Str ACD_2 Start M
Op ACT_2 Operate M
PDUP class
Attribute Name Attr. Type Explanation M/O Notes
RctPwrTripPDUP
(/RctPwrAlmPDUP)
Directional Underpower
Data
Common Logical Node Information
Mod ENC_0 Mode M
Beh ENS_0 Behavior M
Health ENS_1 Health M
NamPlt LPL_1 Name plate M
Status Information
Str ACD_2 Start M
Op ACT_2 Operate M
PosStr ACT_3 Positive pickup O
NegStr ACT_6 Negative pickup O
PosOp ACT_3 Positive Operate O
NegOp ACT_6 Negative Operate O
PTUC class
Attribute Name Attr. Type Explanation M/O Notes
PTUC Undercurrent
Data
Common Logical Node Information
Mod ENC_0 Mode M
Beh ENS_0 Behavior M
Health ENS_1 Health M
NamPlt LPL_1 Name plate M
Status Information
Str ACD_2 Start M
Op ACT_2 Operate M
