B-22 8 SERIES PROTECTIVE RELAY PLATFORM – COMMUNICATIONS GUIDE
MICS CHAPTER B: IEC 61850 IMPLEMENTATION DETAILS
2.4.2 RREC (Autoreclosing)
RREC: Recloser (850)
2.4.3 RFLO (Fault locator)
rptRFLO: Fault report (850)
2.4.4 RBRF (Breaker failure)
RBRF: breaker failure (845, 850, 889)
Status Information
Dir ACD_2 Directions M
Op ACT_5 Directions O
RREC class
Attribute Name Attr. Type Explanation M/O Notes
RREC Autoreclosing element
Data
Common Logical Node Information
Mod ENC_0 Mode M
Beh ENS_0 Behavior M
Health ENS_1 Health M
NamPlt LPL_1 Name plate M
Status Information
Op ACT_2 M
AutoRecSt ENS_3 Operate M
RFLO class
Attribute Name Attr. Type Explanation M/O Notes
rptRFLO Fault locator element
Data
Common Logical Node Information
Mod ENC_0 Mode M
Beh ENS_0 Behavior M
Health ENS_1 Health M
NamPlt LPL_1 Name plate M
Measured Values
FltZ CMV_2 Fault Impedance M
FltDiskm MV_2 Fault Distance in KM O
FltLoop ENS_4 Fault Type O
RecCyc INS_1 Fault Reclose Shot O
RBRF class
Attribute Name Attr. Type Explanation M/O Notes
RBRF Breaker failure element
Data
Common Logical Node Information
Mod ENC_0 Mode M
Beh ENS_0 Behavior M
