CHAPTER B: IEC 61850 IMPLEMENTATION DETAILS MICS
8 SERIES PROTECTIVE RELAY PLATFORM – COMMUNICATIONS GUIDE B-23
RBRF: breaker failure (869)
2.4.5 RSYN (Synchronism-check)
SynChkRSYN: Synchrocheck (845/850/889)
Health ENS_1 Health M
NamPlt LPL_1 Name plate M
Status Information
Str ACD_2 Breaker failure pickup M
OpEx ACT_2 Breaker failure operate M
RBRF class
Attribute Name Attr. Type Explanation M/O Notes
RBRF_1 Breaker failure element
Data
Common Logical Node Information
Mod ENC_0 Mode M
Beh ENS_0 Behavior M
Health ENS_1 Health M
NamPlt LPL_1 Name plate M
Status Information
OpEx ACT_2 Breaker failure operate M
OpIn ACT_2 Breaker failure retrjp C
RSYN class
Attribute Name Attr. Type Explanation M/O Notes
SynChkRSYN Synchronism-check
Data
Common Logical Node Information
Mod ENC_0 Mode M
Beh ENS_0 Behavior M
Health ENS_1 Health M
NamPlt LPL_1 Name plate M
Status Information
Rel SPS_0 M
LivBus SPS_2 O
LivLin SPS_2 O
DeaBus SPS_2 O
DeaLin SPS_2 O
ClsPerm SPS_2 O
Measured values
DifVCIc MV_2 O
DifHzCIc MV_2 O
DifAngCIc MV_2 O
BusVMag MV_3 O
BusVHz MV_3 O
BusVAng MV_3 O
