CHAPTER B: IEC 61850 IMPLEMENTATION DETAILS MICS
8 SERIES PROTECTIVE RELAY PLATFORM – COMMUNICATIONS GUIDE B-25
2.5.2 STMP (Temperature supervision)
RtdSTMP: Temperature supervision
2.5.3 SPTR (Power transformer supervision)
XfmrSPTR: Winding hottest spot (845)
STMP class
Attribute Name Attr.
Type
Explanation M/O Notes
STMP temperature sensor
Data
Common Logical Node Information
Mod ENC_0 Mode M
Beh ENS_0 Behavior M
Health ENS_1 Health M
NamPlt LPL_1 Name plate M
Status Information
Alm SPS_0 O
Trip SPS_0 O
Str ACD_3 O
StrAlm ACD_3 O
OpnCirc SPS_2 O
ShrtCirc SPS_2 O
Measured values
Tmp MV_4 Temperature O
SPTR class
Attribute Name Attr.
Type
Explanation M/O Notes
XfmrSPTR Insulation medium
supervision
Data
Common Logical Node Information
Mod ENC_0 Mode M
Beh ENS_0 Behavior M
Health ENS_1 Health M
NamPlt LPL_1 Name plate M
Status Information
HPTmpOp SPS_0 O
HPTmpStr SPS_2 O
AgeRteStr SPS_2 O
AgeRteOp SPS_2 O
LOLStr SPS_2 O
LOLOp SPS_2 O
Measured values
AgeRte MV_2 O
HPTmpClc MV_2 O
DlyRatLOL MV_3 O
