B-26 8 SERIES PROTECTIVE RELAY PLATFORM – COMMUNICATIONS GUIDE
MICS CHAPTER B: IEC 61850 IMPLEMENTATION DETAILS
2.5.4 SIML (Insulation medium supervision)
DgaSIML: Insulation medium supervision (liquid) (845)
XfmrLfLst MV_3 O
TopOilTmp MV_3 O
AmbTmp MV_3 O
SIML class
Attribute Name Attr.
Type
Explanation M/O Notes
SIML_DGA Insulation medium
supervision
Data
Common Logical Node Information
Mod ENC_0 Mode M
Beh ENS_0 Behavior M
Health ENS_1 Health M
NamPlt LPL_1 Name plate M
Measured values
H2ppm MV_2 Hydrogen in ppm O
N2ppm MV_2 N2 in ppm O
COppm MV_2 CO in ppm O
CO2ppm MV_2 CO2 in ppm O
CH4ppm MV_2 CH4 in ppm O
C2H2ppm MV_2 C2H2 in ppm O
C2H4ppm MV_2 C2H4 in ppm O
C2H6ppm MV_2 C2H6 in ppm O
O2ppm MV_2 O2 in ppm O
MstH2Oppm MV_3 Moisture H2O in ppm O
TDCG MV_3 TDCG O
AmbTmp MV_5 Ambient temperature O
HyH2ppm MV_5 Hydran H2 in ppm O
HyH2HrlTrnd MV_5 Hydran Hourly Trend O
HyH2DlyTrnd MV_5 Hydran Daily Trend O
RHLev MV_3 Percent RH Level O
RHrlAv MV_3 Percent RH Hourly
Average
O
H2OppmLev MV_5 H2O ppm Level O
H2OppmHrlAv MV_5 H2O ppm Hourly
Average
O
