B-28 8 SERIES PROTECTIVE RELAY PLATFORM – COMMUNICATIONS GUIDE
MICS CHAPTER B: IEC 61850 IMPLEMENTATION DETAILS
GGIO4: Virtual Outputs logical node.
GGIO5: Remote Inputs (GOOSE) logical node for 3A/3E option.
NamPlt LPL_1 Name plate M
Status information
Controls
SPCSO1 SPC_1 Single point controllable
status output
O Virtual Input 1
SPCSO2 SPC_1 Single point controllable
status output
O Virtual Input 2
.. .. .. ..
SPCSO64 SPC_1 Single point controllable
status output
O Virtual Input 64
GGIO class
Attribute Name Attr. Type Explanation M/O Notes
GGIO_VO Generic process I/O
Data
Common Logical Node Information
Mod ENC_0 Mode M
Beh ENS_0 Behavior M
Health ENS_1 Health M
NamPlt LPL_1 Name plate M
Status information
Ind1 SPS_0 Ge n e r a l I n d i c a t i o n O Virtual Output 1
Ind2 SPS_0 Ge n e r a l I n d i c a t i o n O Virtual Output 2
.. .. .. ..
Ind96 SPS_0 Ge n e r a l I n d i c a t i o n O Virtual Output 96
GGIO class
Attribute Name Attr. Type Explanation M/O Notes
GGIO_RI Generic process I/O
Data
Common Logical Node Information
Mod ENC_0 Mode M
Beh ENS_0 Behavior M
Health ENS_1 Health M
NamPlt LPL_1 Name plate M
Status information
Ind1 SPS_0 Ge n e r a l I n d i c ati o n O Remote input 1
Ind2 SPS_0 Ge n e r a l I n d i c ati o n O Remote input 2
.. .. .. ..
Ind256 SPS_0 Ge n e r a l I n d i c at i o n O Remote input 256
AnIn1 MV_2 Analog Input O Float type
.. .. .. ..
AnIn24 MV_2 Analog Input O Float type
AnIn25 MV_4 Analog Input O Integer type
.. .. .. ..
AnIn32 MV_4 Analog Input O Integer type
