CHAPTER B: IEC 61850 IMPLEMENTATION DETAILS MICS
8 SERIES PROTECTIVE RELAY PLATFORM – COMMUNICATIONS GUIDE B-29
GGIO5: Remote Inputs (GOOSE) logical node for 2A/2E option.
GGIO6: Contact Outputs logical node
GGIO class
Attribute Name Attr. Type Explanation M/O Notes
GGIO_RI Generic process I/O
Data
Common Logical Node Information
Mod ENC_0 Mode M
Beh ENS_0 Behavior M
Health ENS_1 Health M
NamPlt LPL_1 Name plate M
Status information
Ind1 SPS_0 Ge n e r a l I n d i c a t i o n O Remote input 1
Ind2 SPS_0 Ge n e r a l I n d i c a t i o n O Remote input 2
.. .. .. ..
Ind128 SPS_0 Ge n e r a l I n d i c a t i o n O Remote input 128
AnIn1 MV_2 Analog Input O Float type
.. .. .. ..
AnIn6 MV_2 Analog Input O Float type
AnIn7 MV_4 Analog Input O Integer type
AnIn8 MV_4 Analog Input O Integer type
GGIO class
Attribute Name Attr. Type Explanation M/O Notes
GGIO_CO Generic process I/O
Data
Common Logical Node Information
Mod ENC_0 Mode M
Beh ENS_0 Behavior M
Health ENS_1 Health M
NamPlt LPL_1 Name plate M
Status Information
Ind1 SPS_0 Ge n e r a l I n d i c a t i o n O Contact Output 1
Ind2 SPS_0 Ge n e r a l I n d i c a t i o n O Contact Output 2
Ind3 SPS_0 Ge n e r a l I n d i c a t i o n O
Ind4 SPS_0 Ge n e r a l I n d i c a t i o n O
Ind8 SPS_0 Ge n e r a l I n d i c a t i o n O
Ind9 SPS_0 Ge n e r a l I n d i c a t i o n O
Ind10 SPS_0 Gene r a l I n d i c a t i o n O
Ind11 SPS_0 Gene r a l I n d i c a t i o n O
Ind12 SPS_0 Gene r a l I n d i c a t i o n O
Ind16 SPS_0 Gene r a l I n d i c a t i o n O
Ind17 SPS_0 Gene r a l I n d i c a t i o n O
Ind18 SPS_0 Gene r a l I n d i c a t i o n O
