B-30 8 SERIES PROTECTIVE RELAY PLATFORM – COMMUNICATIONS GUIDE
MICS CHAPTER B: IEC 61850 IMPLEMENTATION DETAILS
2.6.2 GAPC (Generic automatic process control)
FldBkrDspGAPC: Field Breaker Discrepancy (889)
ColdLodGAPC: Cold load (850)
SwOntoFlt: Switch Onto Fault (850)
Ind19 SPS_0 Gen e r a l I n d i c a ti o n O
Ind20 SPS_0 Gen e r a l I n d i c a ti o n O
Ind24 SPS_0 Gen e r a l I n d i c a ti o n O
GAPC class
Attribute Name Attr. Type Explanation M/O/ Notes
FldBkrGAPC Generic Automatic
process control
Data
Common Logical Node Information
Mod ENC_0 Mode M
Beh ENS_0 Behavior M
Health ENS_1 Health M
NamPlt LPL_1 Name plate M
Status information
Str ACD_2 Pickup O
Op ACT_2 Operate O
GAPC class
Attribute Name Attr. Type Explanation M/O/ Notes
ColdLodGAPC/
SwOntoFlt
Generic Automatic
process control
Data
Common Logical Node Information
Mod ENC_0 Mode M
Beh ENS_0 Behavior M
Health ENS_1 Health M
NamPlt LPL_1 Name plate M
Status information
Str ACD_2 O
Op ACT_2 O
