CHAPTER B: IEC 61850 IMPLEMENTATION DETAILS MICS
8 SERIES PROTECTIVE RELAY PLATFORM – COMMUNICATIONS GUIDE B-31
PoleDscGAPC: Pole Discordance logical nodes (850)
CTSupGAPC: CT Supervision logical nodes (850)
GAPC class
Attribute Name Attr. Type Explanation M/O/ Notes
PoleDscGAPC Generic Automatic
process control
Data
Common Logical Node Information
Mod ENC_0 Mode M
Beh ENS_0 Behavior M
Health ENS_1 Health M
NamPlt LPL_1 Name plate M
Status information
Dsc ACT_2 O
DscEx ACT_3 O
DscCon ACT_3 O
DscCur ACT_3 O
DscPhsAFailOpn SPS_2 O
DscPhsBFailOpn SPS_2 O
DscPhsCFailOpn SPS_2 O
DscPhsAFailCls SPS_2 O
DscPhsBFailCls SPS_2 O
DscPhsCFailCls SPS_2 O
GAPC class
Attribute Name Attr. Type Explanation M/O/ Notes
CTSupGAPC Generic Automatic
process control
Data
Common Logical Node Information
Mod ENC_0 Mode M
Beh ENS_0 Behavior M
Health ENS_1 Health M
NamPlt LPL_1 Name plate M
Status information
Str ACD_2 O
Op ACT_2 O
StrSeqChk ACD_3 O
OpSeqChk ACT_3 O
StrDiffChk ACD_3 O
OpDiffChk ACT_3 O
StrSymChk ACD_3 O
OpSymChk ACT_3 O
