CHAPTER B: IEC 61850 IMPLEMENTATION DETAILS MICS
8 SERIES PROTECTIVE RELAY PLATFORM – COMMUNICATIONS GUIDE B-33
MMXU2: Measurements (850, 889-sensitive ground)
KxMMXU1: Measurements (845-Slot K)
KxMMXU: Measurements (889-Slot K)
K1MMXU: Measurements (850-Slot K)
PPV DEL_0 Phase to phase voltages
(VL1L2,...)
O Phase Voltage
PhV WYE_0 Phase to ground voltages
(VL1ER, ...)
O Ground Voltage
A WYE_1 Phase currents (IL1, ...) O Currents
AuxV CMV_1 Auxiliary Phase Voltage O Aux Voltage
MMXU class
Attribute Name Attr. Type Explanation M/O Notes
MMXU_2 Measurement
Data
Common Logical Node Information
Mod ENC_0 Mode M
Beh ENS_0 Behavior M
Health ENS_1 Health M
NamPlt LPL_1 Name plate M
Measured values
A WYE_1 Phase currents (IL1, ...) O Currents
MMXU class
Attribute Name Attr. Type Explanation M/O Notes
MMXU_SLOT_K Measurement
Data
Common Logical Node Information
Mod ENC_0 Mode M
Beh ENS_0 Behavior M
Health ENS_1 Health M
NamPlt LPL_1 Name plate M
Measured values
Hz MV_0 Line Frequency O VLFREC
HzRte MV_1 Line Frequency O VLFREC
A WYE_1 Phase currents (IL1, ...) O Currents
MMXU class
Attribute Name Attr. Type Explanation M/O Notes
MMXU_SLOT_K_2 Measurement
Data
Common Logical Node Information
Mod ENC_0 Mode M
Beh ENS_0 Behavior M
Health ENS_1 Health M
