B-34 8 SERIES PROTECTIVE RELAY PLATFORM – COMMUNICATIONS GUIDE
MICS CHAPTER B: IEC 61850 IMPLEMENTATION DETAILS
K1MMXU1: Measurements (869-Slot K)
K_MMXU: Measurements (889)
CTSupMMXU: CT Supervision Metering (850)
NamPlt LPL_1 Name plate M
Measured values
A WYE_1 Phase currents (IL1, ...) O Currents
MMXU class
Attribute Name Attr. Type Explanation M/O Notes
MMXU_SLOT_K Measurement
Data
Common Logical Node Information
Mod ENC_0 Mode M
Beh ENS_0 Behavior M
Health ENS_1 Health M
NamPlt LPL_1 Name plate M
Measured values
TotW MV_0 Total active power (P) O Real Power
TotVAr MV_0 Total reactive power (Q) O Reactive Power
TotVA MV_0 Total apparent power (S) O Apparent Power
TotPF MV_0 Average power factor (PF) O Power Factor
Hz MV_0 Line Frequency O VLFREC
HzRte MV_1 Line Frequency O VLFREC
A WYE_1 Phase currents (IL1, ...) O Currents
MMXU class
Attribute Name Attr. Type Explanation M/O Notes
MMXU_SLOT_K_VO
LTAGE
Measurement
Data
Common Logical Node Information
Mod ENC_0 Mode M
Beh ENS_0 Behavior M
Health ENS_1 Health M
NamPlt LPL_1 Name plate M
Measured values
A WYE_1 Phase currents (IL1, ...) O Currents
PPV DEL_0 O
PhV WYE_0 O
MMXU class
Attribute Name Attr. Type Explanation M/O Notes
MMXU_CTS Measurement
Data
Common Logical Node Information
Mod ENC_0 Mode M
