B-42 8 SERIES PROTECTIVE RELAY PLATFORM – COMMUNICATIONS GUIDE
MICS CHAPTER B: IEC 61850 IMPLEMENTATION DETAILS
(869, 889)
(869, 889)
ENS_3 (AutoRecSt)
Attribute
Name Attribute Type FC TrgOp Value/Value Range M/O/C
DataAttribute
status
stVal Enumerated ST dchg Close, Lockout, In
progress,...
M
q BVstring13 ST qchg M
t Utctime ST M
d Vstring255 DC O
ENS_4 (Fault Type)
Attribute
Name Attribute Type FC TrgOp Value/Value Range M/O/C
DataAttribute
status
stVal Enumerated ST dchg 1, 2, 3, 4, 5, 6, other M
q BVstring13 ST qchg M
t Utctime ST M
d Vstring255 DC O
dataNs Vstring255 EX
ENS_5 (GeneratorSt)
Attribute
Name Attribute Type FC TrgOp Value/Value Range M/O/C
DataAttribute
status
stVal Enumerated ST dchg Stopped, Stopping,
Started…
for 869:
Motor Status Tripped =>
Stopped (1)
Motor Status Stopped =>
Stopped (1)
Motor Status Starting =>
Starting (4)
Motor Status Running =>
Started (3)
Motor Status Overload =>
Started (3)
M
q BVstring13 ST qchg M
t Utctime ST M
d Vstring255 DC O
