CHAPTER B: IEC 61850 IMPLEMENTATION DETAILS MICS
8 SERIES PROTECTIVE RELAY PLATFORM – COMMUNICATIONS GUIDE B-43
3.1.4 Protection activation information (ACT)
ACT_0
Attribute Name Attribute Type FC TrgOp Value/Value Range M/O/C
DataAttribute
control and status
general Boolean ST dchg M
phsA Boolean ST dchg O
phsB Boolean ST dchg O
phsC Boolean ST dchg O
q Bvstring13 ST qchg M
t Utctime ST M
configuration, description and extension
d Vstring255 DC O
ACT_1
Attribute Name Attribute Type FC TrgOp Value/Value Range M/O/C
DataAttribute
control and status
general Boolean ST dchg M
neut Boolean ST dchg O
q Bvstring13 ST qchg M
t Utctime ST M
configuration, description and extension
d Vstring255 DC O
ACT_2
Attribute Name Attribute Type FC TrgOp Value/Value Range M/O/C
DataAttribute
control and status
general Boolean ST dchg M
q Bvstring13 ST qchg M
t Utctime ST M
configuration, description and extension
d Vstring255 DC O
ACT_3
Attribute Name Attribute Type FC TrgOp Value/Value Range M/O/C
DataAttribute
control and status
general Boolean ST dchg M
q Bvstring13 ST qchg M
t Utctime ST M
configuration, description and extension
d Vstring255 DC O
dataNs Vstring255 EX M
