B-50 8 SERIES PROTECTIVE RELAY PLATFORM – COMMUNICATIONS GUIDE
MICS CHAPTER B: IEC 61850 IMPLEMENTATION DETAILS
3.2.3 Phase to ground related measured values of a three phase system (WYE)
(845, 869, 889)
(845, 869, 889)
WYE_0
Attribute Name Attribute Type FC TrgOp Value/Value Range M/O/C
Data
phsA CMV_0 GC_1
phsB CMV_0 GC_1
phsC CMV_0 GC_1
neut CMV_0 GC_1
configuration, description and extension
d Vstring255 DC O
WYE_1
Attribute Name Attribute Type FC TrgOp Value/Value Range M/O/C
Data
phsA CMV_0 GC_1
phsB CMV_0 GC_1
phsC CMV_0 GC_1
neut CMV_0 GC_1
net CMV_0 GC_1
res CMV_0 GC_1
configuration, description and extension
d Vstring255 DC O
WYE_2
Attribute Name Attribute Type FC TrgOp Value/Value Range M/O/C
Data
phsA CMV_0 GC_1
phsB CMV_0 GC_1
phsC CMV_0 GC_1
neut CMV_0 GC_1
neut CMV_0 GC_1
net CMV_0 GC_1
configuration, description and extension
d Vstring255 DC O
WYE_3
Attribute Name Attribute Type FC TrgOp Value/Value Range M/O/C
Data
phsA CMV_0 GC_1
phsB CMV_0 GC_1
phsC CMV_0 GC_1
configuration, description and extension
d Vstring255 DC O
