CHAPTER B: IEC 61850 IMPLEMENTATION DETAILS MICS
8 SERIES PROTECTIVE RELAY PLATFORM – COMMUNICATIONS GUIDE B-51
(845, 869, 889)
3.2.4 Phase to phase related measured values of a three phase system ( DEL )
3.2.5 Sequence (SEQ)
3.2.6 Sampled value (SAV)
WYE_4
Attribute Name Attribute Type FC TrgOp Value/Value Range M/O/C
Data
phsA CMV_0 GC_1
phsB CMV_0 GC_1
phsC CMV_0 GC_1
configuration, description and extension
d Vstring255 DC O
DEL_0
Attribute Name Attribute Type FC TrgOp Value/Value Range M/O/C
Data
phsAB CMV_0 GC_1
phsBC CMV_0 GC_1
phsCA CMV_0 GC_1
configuration, description and extension
d Vstring255 DC O
SEQ_0
Attribute Name Attribute Type FC TrgOp Value/Value Range M/O/C
Data
c1 CMV_0 GC_1
c2 CMV_0 GC_1
c3 CMV_0 GC_1
Measured attributes
seqT enumerated MX Pos-neg-zero | dir-quad-
zero
O
configuration, description and extension
d Vstring255 DC O
SAV_0
Attribute
Name
Attribute Type FC TrgOp Value/Value Range M/O/C
DataAttribute
Measured attributes
instMag IntAnalogueValue MX ----- M
i INT32 M
q BVstring13 MX qchg M
t Utctime MX O
configuration, description and extension
units Unit CF O
