B-12 F35 Multiple Feeder Protection System GE Multilin
B.4 MEMORY MAPPING APPENDIX B
B
1C02 Source 1 Phase A Real Power -1000000000000 to
1000000000000
W 0.001 F060 0
1C04 Source 1 Phase B Real Power -1000000000000 to
1000000000000
W 0.001 F060 0
1C06 Source 1 Phase C Real Power -1000000000000 to
1000000000000
W 0.001 F060 0
1C08 Source 1 Three Phase Reactive Power -1000000000000 to
1000000000000
var 0.001 F060 0
1C0A Source 1 Phase A Reactive Power -1000000000000 to
1000000000000
var 0.001 F060 0
1C0C Source 1 Phase B Reactive Power -1000000000000 to
1000000000000
var 0.001 F060 0
1C0E Source 1 Phase C Reactive Power -1000000000000 to
1000000000000
var 0.001 F060 0
1C10 Source 1 Three Phase Apparent Power -1000000000000 to
1000000000000
VA 0.001 F060 0
1C12 Source 1 Phase A Apparent Power -1000000000000 to
1000000000000
VA 0.001 F060 0
1C14 Source 1 Phase B Apparent Power -1000000000000 to
1000000000000
VA 0.001 F060 0
1C16 Source 1 Phase C Apparent Power -1000000000000 to
1000000000000
VA 0.001 F060 0
1C18 Source 1 Three Phase Power Factor -0.999 to 1 --- 0.001 F013 0
1C19 Source 1 Phase A Power Factor -0.999 to 1 --- 0.001 F013 0
1C1A Source 1 Phase B Power Factor -0.999 to 1 --- 0.001 F013 0
1C1B Source 1 Phase C Power Factor -0.999 to 1 --- 0.001 F013 0
1C1C Reserved (4 items) --- --- --- F001 0
1C20 ...Repeated for Source 2
1C40 ...Repeated for Source 3
1C60 ...Repeated for Source 4
1C80 ...Repeated for Source 5
1CA0 ...Repeated for Source 6
Source Energy (Read Only Non-Volatile) (6 modules)
1D00 Source 1 Positive Watthour 0 to 1000000000000 Wh 0.001 F060 0
1D02 Source 1 Negative Watthour 0 to 1000000000000 Wh 0.001 F060 0
1D04 Source 1 Positive Varhour 0 to 1000000000000 varh 0.001 F060 0
1D06 Source 1 Negative Varhour 0 to 1000000000000 varh 0.001 F060 0
1D08 Reserved (8 items) --- --- --- F001 0
1D10 ...Repeated for Source 2
1D20 ...Repeated for Source 3
1D30 ...Repeated for Source 4
1D40 ...Repeated for Source 5
1D50 ...Repeated for Source 6
Energy Commands (Read/Write Command)
1D60 Energy Clear Command 0 to 1 --- 1 F126 0 (No)
Source Frequency (Read Only) (6 modules)
1D80 Frequency for Source 1 --- Hz --- F003 0
1D82 Frequency for Source 2 --- Hz --- F003 0
1D84 Frequency for Source 3 --- Hz --- F003 0
1D86 Frequency for Source 4 --- Hz --- F003 0
1D88 Frequency for Source 5 --- Hz --- F003 0
1D8A Frequency for Source 6 --- Hz --- F003 0
Source Demand (Read Only) (6 modules)
1E00 Source 1 Demand Ia 0 to 999999.999 A 0.001 F060 0
1E02 Source 1 Demand Ib 0 to 999999.999 A 0.001 F060 0
1E04 Source 1 Demand Ic 0 to 999999.999 A 0.001 F060 0
1E06 Source 1 Demand Watt 0 to 999999.999 W 0.001 F060 0
1E08 Source 1 Demand Var 0 to 999999.999 var 0.001 F060 0
Table B–9: MODBUS MEMORY MAP (Sheet 5 of 48)
