GE Multilin F35 - Page 363

GE Multilin F35 Multiple Feeder Protection System B-13
APPENDIX B B.4 MEMORY MAPPING
B
1E0A Source 1 Demand Va 0 to 999999.999 VA 0.001 F060 0
1E0C Reserved (4 items) --- --- --- F001 0
1E10 ...Repeated for Source 2
1E20 ...Repeated for Source 3
1E30 ...Repeated for Source 4
1E40 ...Repeated for Source 5
1E50 ...Repeated for Source 6
Source Demand Peaks (Read Only Non-Volatile) (6 modules)
1E80 Source 1 Demand Ia Maximum 0 to 999999.999 A 0.001 F060 0
1E82 Source 1 Demand Ia Maximum Date 0 to 4294967295 --- 1 F050 0
1E84 Source 1 Demand Ib Maximum 0 to 999999.999 A 0.001 F060 0
1E86 Source 1 Demand Ib Maximum Date 0 to 4294967295 --- 1 F050 0
1E88 Source 1 Demand Ic Maximum 0 to 999999.999 A 0.001 F060 0
1E8A Source 1 Demand Ic Maximum Date 0 to 4294967295 --- 1 F050 0
1E8C Source 1 Demand Watt Maximum 0 to 999999.999 W 0.001 F060 0
1E8E Source 1 Demand Watt Maximum Date 0 to 4294967295 --- 1 F050 0
1E90 Source 1 Demand Var 0 to 999999.999 var 0.001 F060 0
1E92 Source 1 Demand Var Maximum Date 0 to 4294967295 --- 1 F050 0
1E94 Source 1 Demand Va Maximum 0 to 999999.999 VA 0.001 F060 0
1E96 Source 1 Demand Va Maximum Date 0 to 4294967295 --- 1 F050 0
1E98 Reserved (8 items) --- --- --- F001 0
1EA0 ...Repeated for Source 2
1EC0 ...Repeated for Source 3
1EE0 ...Repeated for Source 4
1F00 ...Repeated for Source 5
1F20 ...Repeated for Source 6
Source Voltage THD And Harmonics (Read Only) (6 modules)
1F80 Source 1 Va THD 0 to 99.9 --- 0.1 F001 0
1F81 Source 1 Va Harmonics - 2nd to 25th (24 items) 0 to 99.9 --- 0.1 F001 0
1F99 Source 1 Vb THD 0 to 99.9 --- 0.1 F001 0
1F9A Source 1 Vb Harmonics - 2nd to 25th (24 items) 0 to 99.9 --- 0.1 F001 0
1FB2 Source 1 Vc THD 0 to 99.9 --- 0.1 F001 0
1FB3 Source 1 Vc Harmonics - 2nd to 25th (24 items) 0 to 99.9 --- 0.1 F001 0
1FCB ...Repeated for Source 2
2016 ...Repeated for Source 3
2061 ...Repeated for Source 4
20AC ...Repeated for Source 5
20F7 ...Repeated for Source 6
Breaker Arcing Current Actuals (Read Only Non-Volatile) (2 modules)
21E0 Breaker 1 Arcing Current Phase A 0 to 99999999 kA
2
-cyc 1 F060 0
21E2 Breaker 1 Arcing Current Phase B 0 to 99999999 kA
2
-cyc 1 F060 0
21E4 Breaker 1 Arcing Current Phase C 0 to 99999999 kA
2
-cyc 1 F060 0
21E6 Breaker 1 Operating Time Phase A 0 to 65535 ms 1 F001 0
21E7 Breaker 1 Operating Time Phase B 0 to 65535 ms 1 F001 0
21E8 Breaker 1 Operating Time Phase C 0 to 65535 ms 1 F001 0
21E9 Breaker 1 Operating Time 0 to 65535 ms 1 F001 0
21EA ...Repeated for Breaker Arcing Current 2
Breaker Arcing Current Commands (Read/Write Command) (2 modules)
2224 Breaker 1 Arcing Current Clear Command 0 to 1 --- 1 F126 0 (No)
2225 Breaker 2 Arcing Current Clear Command 0 to 1 --- 1 F126 0 (No)
Passwords Unauthorized Access (Read/Write Command)
2230 Reset Unauthorized Access 0 to 1 --- 1 F126 0 (No)
Fault Location (Read Only) (5 modules)
2340 Fault 1 Prefault Phase A Current Magnitude 0 to 999999.999 A 0.001 F060 0
Table B–9: MODBUS MEMORY MAP (Sheet 6 of 48)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
