GE Multilin F35 Multiple Feeder Protection System B-15
APPENDIX B B.4 MEMORY MAPPING
B
Fault Report Indexing (Read Only Non-Volatile)
3020 Number of Fault Reports 0 to 65535 --- 1 F001 0
Fault Report Actuals (Read Only Non-Volatile) (15 modules)
3030 Fault Report 1 Time 0 to 4294967295 --- 1 F050 0
3032 Fault Report 2 Time 0 to 4294967295 --- 1 F050 0
3034 Fault Report 3 Time 0 to 4294967295 --- 1 F050 0
3036 Fault Report 4 Time 0 to 4294967295 --- 1 F050 0
3038 Fault Report 5 Time 0 to 4294967295 --- 1 F050 0
303A Fault Report 6 Time 0 to 4294967295 --- 1 F050 0
303C Fault Report 7 Time 0 to 4294967295 --- 1 F050 0
303E Fault Report 8 Time 0 to 4294967295 --- 1 F050 0
3040 Fault Report 9 Time 0 to 4294967295 --- 1 F050 0
3042 Fault Report 10 Time 0 to 4294967295 --- 1 F050 0
3044 Fault Report 11 Time 0 to 4294967295 --- 1 F050 0
3046 Fault Report 12 Time 0 to 4294967295 --- 1 F050 0
3048 Fault Report 13 Time 0 to 4294967295 --- 1 F050 0
304A Fault Report 14 Time 0 to 4294967295 --- 1 F050 0
304C Fault Report 15 Time 0 to 4294967295 --- 1 F050 0
Modbus file transfer (read/write)
3100 Name of file to read --- --- --- F204 (none)
Modbus file transfer values (read only)
3200 Character position of current block within file 0 to 4294967295 --- 1 F003 0
3202 Size of currently-available data block 0 to 65535 --- 1 F001 0
3203 Block of data from requested file (122 items) 0 to 65535 --- 1 F001 0
Event recorder actual values (read only)
3400 Events Since Last Clear 0 to 4294967295 --- 1 F003 0
3402 Number of Available Events 0 to 4294967295 --- 1 F003 0
3404 Event Recorder Last Cleared Date 0 to 4294967295 --- 1 F050 0
Event recorder commands (read/write)
3406 Event Recorder Clear Command 0 to 1 --- 1 F126 0 (No)
DCMA Input Values (Read Only) (24 modules)
34C0 DCMA Inputs 1 Value -9999999 to 9999999 --- 1 F004 0
34C2 DCMA Inputs 2 Value -9999999 to 9999999 --- 1 F004 0
34C4 DCMA Inputs 3 Value -9999999 to 9999999 --- 1 F004 0
34C6 DCMA Inputs 4 Value -9999999 to 9999999 --- 1 F004 0
34C8 DCMA Inputs 5 Value -9999999 to 9999999 --- 1 F004 0
34CA DCMA Inputs 6 Value -9999999 to 9999999 --- 1 F004 0
34CC DCMA Inputs 7 Value -9999999 to 9999999 --- 1 F004 0
34CE DCMA Inputs 8 Value -9999999 to 9999999 --- 1 F004 0
34D0 DCMA Inputs 9 Value -9999999 to 9999999 --- 1 F004 0
34D2 DCMA Inputs 10 Value -9999999 to 9999999 --- 1 F004 0
34D4 DCMA Inputs 11 Value -9999999 to 9999999 --- 1 F004 0
34D6 DCMA Inputs 12 Value -9999999 to 9999999 --- 1 F004 0
34D8 DCMA Inputs 13 Value -9999999 to 9999999 --- 1 F004 0
34DA DCMA Inputs 14 Value -9999999 to 9999999 --- 1 F004 0
34DC DCMA Inputs 15 Value -9999999 to 9999999 --- 1 F004 0
34DE DCMA Inputs 16 Value -9999999 to 9999999 --- 1 F004 0
34E0 DCMA Inputs 17 Value -9999999 to 9999999 --- 1 F004 0
34E2 DCMA Inputs 18 Value -9999999 to 9999999 --- 1 F004 0
34E4 DCMA Inputs 19 Value -9999999 to 9999999 --- 1 F004 0
34E6 DCMA Inputs 20 Value -9999999 to 9999999 --- 1 F004 0
34E8 DCMA Inputs 21 Value -9999999 to 9999999 --- 1 F004 0
34EA DCMA Inputs 22 Value -9999999 to 9999999 --- 1 F004 0
34EC DCMA Inputs 23 Value -9999999 to 9999999 --- 1 F004 0
Table B–9: MODBUS MEMORY MAP (Sheet 8 of 48)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
