B-20 F35 Multiple Feeder Protection System GE Multilin
B.4 MEMORY MAPPING APPENDIX B
B
428A ...Repeated for User-Programmable LED 6
428C ...Repeated for User-Programmable LED 7
428E ...Repeated for User-Programmable LED 8
4290 ...Repeated for User-Programmable LED 9
4292 ...Repeated for User-Programmable LED 10
4294 ...Repeated for User-Programmable LED 11
4296 ...Repeated for User-Programmable LED 12
4298 ...Repeated for User-Programmable LED 13
429A ...Repeated for User-Programmable LED 14
429C ...Repeated for User-Programmable LED 15
429E ...Repeated for User-Programmable LED 16
42A0 ...Repeated for User-Programmable LED 17
42A2 ...Repeated for User-Programmable LED 18
42A4 ...Repeated for User-Programmable LED 19
42A6 ...Repeated for User-Programmable LED 20
42A8 ...Repeated for User-Programmable LED 21
42AA ...Repeated for User-Programmable LED 22
42AC ...Repeated for User-Programmable LED 23
42AE ...Repeated for User-Programmable LED 24
42B0 ...Repeated for User-Programmable LED 25
42B2 ...Repeated for User-Programmable LED 26
42B4 ...Repeated for User-Programmable LED 27
42B6 ...Repeated for User-Programmable LED 28
42B8 ...Repeated for User-Programmable LED 29
42BA ...Repeated for User-Programmable LED 30
42BC ...Repeated for User-Programmable LED 31
42BE ...Repeated for User-Programmable LED 32
42C0 ...Repeated for User-Programmable LED 33
42C2 ...Repeated for User-Programmable LED 34
42C4 ...Repeated for User-Programmable LED 35
42C6 ...Repeated for User-Programmable LED 36
42C8 ...Repeated for User-Programmable LED 37
42CA ...Repeated for User-Programmable LED 38
42CC ...Repeated for User-Programmable LED 39
42CE ...Repeated for User-Programmable LED 40
42D0 ...Repeated for User-Programmable LED 41
42D2 ...Repeated for User-Programmable LED 42
42D4 ...Repeated for User-Programmable LED 43
42D6 ...Repeated for User-Programmable LED 44
42D8 ...Repeated for User-Programmable LED 45
42DA ...Repeated for User-Programmable LED 46
42DC ...Repeated for User-Programmable LED 47
42DE ...Repeated for User-Programmable LED 48
Installation (Read/Write Setting)
43E0 Relay Programmed State 0 to 1 --- 1 F133 0 (Not Programmed)
43E1 Relay Name --- --- --- F202 “Relay-1”
User Programmable Self Tests (Read/Write Setting)
4441 User Programmable Detect Ring Break Function 0 to 1 --- 1 F102 1 (Enabled)
4442 User Programmable Direct Device Off Function 0 to 1 --- 1 F102 1 (Enabled)
4443 User Programmable Remote Device Off Function 0 to 1 --- 1 F102 1 (Enabled)
4444 User Programmable Primary Ethernet Fail Function 0 to 1 --- 1 F102 0 (Disabled)
4445 User Programmable Secondary Ethernet Fail Function 0 to 1 --- 1 F102 0 (Disabled)
4446 User Programmable Battery Fail Function 0 to 1 --- 1 F102 1 (Enabled)
4447 User Programmable SNTP Fail Function 0 to 1 --- 1 F102 1 (Enabled)
Table B–9: MODBUS MEMORY MAP (Sheet 13 of 48)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
To Next Page
