B-22 F35 Multiple Feeder Protection System GE Multilin
B.4 MEMORY MAPPING APPENDIX B
B
Breaker control (read/write settings)
4700 Breaker 1 function 0 to 1 --- 1 F102 0 (Disabled)
4701 Breaker 1 name --- --- --- F206 “Bkr 1"
4704 Breaker 1 mode 0 to 1 --- 1 F157 0 (3-Pole)
4705 Breaker 1 open 0 to 65535 --- 1 F300 0
4706 Breaker 1 close 0 to 65535 --- 1 F300 0
4707 Breaker 1 phase A / three-pole closed 0 to 65535 --- 1 F300 0
4708 Breaker 1 phase B closed 0 to 65535 --- 1 F300 0
4709 Breaker 1 phase C closed 0 to 65535 --- 1 F300 0
470A Breaker 1 external alarm 0 to 65535 --- 1 F300 0
470B Breaker 1 alarm delay 0 to 1000000 s 0.001 F003 0
470D Breaker 1 pushbutton control 0 to 1 --- 1 F102 0 (Disabled)
470E Breaker 1 manual close recall time 0 to 1000000 s 0.001 F003 0
4710 Breaker 1 out of service 0 to 65535 --- 1 F300 0
4711 Breaker 1 block open 0 to 65535 --- 1 F300 0
4712 Breaker 1 block close 0 to 65535 --- 1 F300 0
4713 Breaker 1 phase A / three-pole opened 0 to 65535 --- 1 F300 0
4714 Breaker 1 phase B opened 0 to 65535 --- 1 F300 0
4715 Breaker 1 phase C opened 0 to 65535 --- 1 F300 0
4716 Breaker 1 operate time 0 to 2 s 0.001 F001 70
4717 Breaker 1 events 0 to 1 --- 1 F102 0 (Disabled)
4718 Reserved --- --- --- --- ---
4719 ...Repeated for breaker 2
4732 ...Repeated for breaker 3
474B ...Repeated for breaker 4
4764 ...Repeated for breaker 5
477D ...Repeated for breaker 6
Demand (Read/Write Setting)
47D0 Demand Current Method 0 to 2 --- 1 F139 0 (Thrm. Exponential)
47D1 Demand Power Method 0 to 2 --- 1 F139 0 (Thrm. Exponential)
47D2 Demand Interval 0 to 5 --- 1 F132 2 (15 MIN)
47D3 Demand Input 0 to 65535 --- 1 F300 0
Demand (Read/Write Command)
47D4 Demand Clear Record 0 to 1 --- 1 F126 0 (No)
Flexcurves A and B (Read/Write Settings)
4800 FlexCurve A (120 items) 0 to 65535 ms 1 F011 0
48F0 FlexCurve B (120 items) 0 to 65535 ms 1 F011 0
Modbus User Map (Read/Write Setting)
4A00 Modbus Address Settings for User Map (256 items) 0 to 65535 --- 1 F001 0
User Displays Settings (Read/Write Setting) (16 modules)
4C00 User-Definable Display 1 Top Line Text --- --- --- F202 “ “
4C0A User-Definable Display 1 Bottom Line Text --- --- --- F202 ““
4C14 Modbus Addresses of Display 1 Items (5 items) 0 to 65535 --- 1 F001 0
4C19 Reserved (7 items) --- --- --- F001 0
4C20 ...Repeated for User-Definable Display 2
4C40 ...Repeated for User-Definable Display 3
4C60 ...Repeated for User-Definable Display 4
4C80 ...Repeated for User-Definable Display 5
4CA0 ...Repeated for User-Definable Display 6
4CC0 ...Repeated for User-Definable Display 7
4CE0 ...Repeated for User-Definable Display 8
4D00 ...Repeated for User-Definable Display 9
4D20 ...Repeated for User-Definable Display 10
4D40 ...Repeated for User-Definable Display 11
Table B–9: MODBUS MEMORY MAP (Sheet 15 of 48)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
To Next Page
