B-28 F35 Multiple Feeder Protection System GE Multilin
B.4 MEMORY MAPPING APPENDIX B
B
6247 Autoreclose 1 Reset Lockout On Manual Close 0 to 1 --- 1 F108 0 (Off)
6248 Autoreclose 1 Breaker Closed 0 to 65535 --- 1 F300 0
6249 Autoreclose 1 Breaker Open 0 to 65535 --- 1 F300 0
624A Autoreclose 1 Block Time Upon Manual Close 0 to 655.35 s 0.01 F001 1000
624B Autoreclose 1 Dead Time Shot 1 0 to 655.35 s 0.01 F001 100
624C Autoreclose 1 Dead Time Shot 2 0 to 655.35 s 0.01 F001 200
624D Autoreclose 1 Dead Time Shot 3 0 to 655.35 s 0.01 F001 300
624E Autoreclose 1 Dead Time Shot 4 0 to 655.35 s 0.01 F001 400
624F Autoreclose 1 Reset Lockout Delay 0 to 655.35 s 0.01 F001 6000
6250 Autoreclose 1 Reset Time 0 to 655.35 s 0.01 F001 6000
6251 Autoreclose 1 Incomplete Sequence Time 0 to 655.35 s 0.01 F001 500
6252 Autoreclose 1 Events 0 to 1 --- 1 F102 0 (Disabled)
6253 Autoreclose 1 Reduce Max 1 0 to 65535 --- 1 F300 0
6254 Autoreclose 1 Reduce Max 2 0 to 65535 --- 1 F300 0
6255 Autoreclose 1 Reduce Max 3 0 to 65535 --- 1 F300 0
6256 Autoreclose 1 Add Delay 1 0 to 65535 --- 1 F300 0
6257 Autoreclose 1 Delay 1 0 to 655.35 s 0.01 F001 0
6258 Autoreclose 1 Add Delay 2 0 to 65535 --- 1 F300 0
6259 Autoreclose 1 Delay 2 0 to 655.35 s 0.01 F001 0
625A Reserved (4 items) 0 to 0.001 --- 0.001 F001 0
625E ...Repeated for Autoreclose 2
627C ...Repeated for Autoreclose 3
629A ...Repeated for Autoreclose 4
62B8 ...Repeated for Autoreclose 5
62D6 ...Repeated for Autoreclose 6
Phase Undervoltage (Read/Write Grouped Setting) (2 modules)
7000 Phase Undervoltage 1 Function 0 to 1 --- 1 F102 0 (Disabled)
7001 Phase Undervoltage 1 Signal Source 0 to 5 --- 1 F167 0 (SRC 1)
7002 Phase Undervoltage 1 Pickup 0 to 3 pu 0.001 F001 1000
7003 Phase Undervoltage 1 Curve 0 to 1 --- 1 F111 0 (Definite Time)
7004 Phase Undervoltage 1 Delay 0 to 600 s 0.01 F001 100
7005 Phase Undervoltage 1 Minimum Voltage 0 to 3 pu 0.001 F001 100
7006 Phase Undervoltage 1 Block 0 to 65535 --- 1 F300 0
7007 Phase Undervoltage 1 Target 0 to 2 --- 1 F109 0 (Self-reset)
7008 Phase Undervoltage 1 Events 0 to 1 --- 1 F102 0 (Disabled)
7009 Phase Undervoltage 1 Measurement Mode 0 to 1 --- 1 F186 0 (Phase to Ground)
700A Reserved (6 items) 0 to 1 --- 1 F001 0
7013 ...Repeated for Phase Undervoltage 2
Breaker Arcing Current Settings (Read/Write Setting) (2 modules)
72C0 Breaker 1 Arcing Current Function 0 to 1 --- 1 F102 0 (Disabled)
72C1 Breaker 1 Arcing Current Source 0 to 5 --- 1 F167 0 (SRC 1)
72C2 Breaker 1 Arcing Current Initiate A 0 to 65535 --- 1 F300 0
72C3 Breaker 1 Arcing Current Initiate B 0 to 65535 --- 1 F300 0
72C4 Breaker 1 Arcing Current Initiate C 0 to 65535 --- 1 F300 0
72C5 Breaker 1 Arcing Current Delay 0 to 65.535 s 0.001 F001 0
72C6 Breaker 1 Arcing Current Limit 0 to 50000 kA
2
-cyc 1 F001 1000
72C7 Breaker 1 Arcing Current Block 0 to 65535 --- 1 F300 0
72C8 Breaker 1 Arcing Current Target 0 to 2 --- 1 F109 0 (Self-reset)
72C9 Breaker 1 Arcing Current Events 0 to 1 --- 1 F102 0 (Disabled)
72CA ...Repeated for Breaker 2 Arcing Current
72D4 ...Repeated for Breaker 3 Arcing Current
72DE ...Repeated for Breaker 4 Arcing Current
72E8 ...Repeated for Breaker 5 Arcing Current
72F2 ...Repeated for Breaker 6 Arcing Current
Table B–9: MODBUS MEMORY MAP (Sheet 21 of 48)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
