6.4 MEMORY MAP 6 COMMUNICATIONS
6
GENERAL
SWITCH D
continued
13D3 General Switch D Trip Relays 0 3 1 - FC111 0
13D4 General Switch D Trip Delay 1 50000 1 s F2 50
13D5 Reserved
...
14FF Reserved
RELAY RESET
MODE
1500 Reset Mode R1 TRIP 0 2 1 - FC117 0
1501 Reset Mode R2 AUXILIARY 0 2 1 - FC117 0
1502 Reset Mode R3 AUXILIARY 0 2 1 - FC117 0
1503 Reset Mode R4 ALARM 0 2 1 - FC117 0
1504 Reserved
1505 Reset Mode R6 SERVICE 0 2 1 - FC117 0
FORCE
OUTPUT
RELAY
1506 Force R1 Output Relay 0 1 1 - FC126 0
1507 Force R1 Operate Time 0 300 1 s F1 0
1508 Force R2 Output Relay 0 1 1 - FC126 0
1509 Force R2 Operate Time 0 300 1 s F1 0
150A Force R3 Output Relay 0 1 1 - FC126 0
150B Force R3 Operate Time 0 300 1 s F1 0
150C Force R4 Output Relay 0 1 1 - FC126 0
150D Force R4 Operate Time 0 300 1 s F1 0
150E Force R5 Output Relay 0 1 1 - FC126 0
150F Force R5 Operate Time 0 300 1 s F1 0
1510 Reserved
...
157F Reserved
THERMAL
MODEL
1580 Curve Style 0 2 1 - FC128 0
1581 Overload Pickup Level 101 125 1
×
FLA F3 101
1582 Unbalance k Factor 0 12 1 - F1 0
1582 Unbalance k Factor 0 12 1 - F1 0
1583 Cool Time Constant Running 1 1000 1 min F1 15
1584 Cool Time Constant Stopped 1 1000 1 min F1 30
1585 Hot/Cold Safe Stall Ratio 1 100 1 - F3 100
1586 RTD Biasing 0 1 1 - FC103 0
1587 RTD Bias Minimum 0 250 1 °C F1 40
1588 RTD Bias Center Point 0 250 1 °C F1 130
1589 RTD Bias Maximum 0 250 1 °C F1 155
158A Thermal Capacity Alarm 0 2 1 - FC115 0
158B Thermal Capacity Alarm Relays 0 6 1 - FC113 0
158C Thermal Capacity Alarm Level 10 100 1 %used F1 75
158D Thermal Capacity Alarm Events 0 1 1 - FC103 0
158E Overload Trip Relays 0 3 1 - FC111 0
158F Reserved
...
15AE Reserved
Table 6–1: 469 MEMORY MAP (Sheet 17 of 43)
GROUP ADDR
(HEX)
DESCRIPTION MIN. MAX. STEP
VALUE
UNITS FORMAT
CODE
DEFAULT
