GE 469

6-36 469 Motor Management Relay GE Power Management
6.4 MEMORY MAP 6 COMMUNICATIONS
6
163F Reserved
SHORT
CIRCUIT TRIP
1640 Short Circuit Trip 0 2 1 - FC115 0
1641 Overreach Filter 0 1 1 - FC103 0
1642 Short Circuit Trip Relays 0 6 1 - FC118 0
1643 Short Circuit Trip Pickup 20 200 1
×
CT F2 100
1644 Intentional Short Circuit Trip Delay 0 1000 10 ms F1 0
1645 Short Circuit Trip Backup 0 1 1 - FC103 0
1646 Short Circuit Backup Relays 0 2 1 - FC119 0
1647 Short Circuit Trip Backup Delay 10 2000 10 ms F1 200
1648 Reserved
---
164F Reserved
OVERLOAD
ALARM
1650 Overload Alarm 0 2 1 - FC115 0
1651 Overload Alarm Relays 0 6 1 - FC113 0
1652 Overload Alarm Events 0 1 1 - FC103 0
1653 Overload Alarm Delay 1 600 1 s F2 0
1654 Reserved
...
165F Reserved
MECHANICAL
JAM
1660 Mechanical Jam Trip 0 2 1 - FC115 0
1661 Mechanical Jam Trip Relays 0 3 1 - FC111 0
1662 Mechanical Jam Pickup 101 300 1
×
FLA F3 150
1663 Mechanical Jam Delay 1 30 1 s F1 1
1664 Reserved
...
166F Reserved
UNDERCUR-
RENT
1670 Block Undercurrent from Start 0 15000 1 s F1 0
1671 Undercurrent Alarm 0 2 1 - FC115 0
1672 Undercurrent Alarm Relays 0 6 1 - FC113 0
1673 Undercurrent Alarm Pickup 10 95 1
×
FLA F3 70
1674 Undercurrent Alarm Delay 1 60 1 s F1 1
1675 Undercurrent Alarm Events 0 1 1 - FC103 0
1676 Undercurrent Trip 0 2 1 - FC115 0
1677 Undercurrent Trip Relays 0 3 1 - FC111 0
1678 Undercurrent Trip Pickup 10 99 1
×
FLA F3 70
1679 Undercurrent Trip Delay 1 60 1 s F1 1
167A Reserved
...
167F Reserved
Table 6–1: 469 MEMORY MAP (Sheet 19 of 43)
GROUP ADDR
(HEX)
DESCRIPTION MIN. MAX. STEP
VALUE
UNITS FORMAT
CODE
DEFAULT
