6-38 469 Motor Management Relay GE Power Management
6.4 MEMORY MAP 6 COMMUNICATIONS
6
ACCELERA-
TION TIMER
16D0 Acceleration Timer Trip 0 2 1 - FC115 0
16D1 Acceleration Timer Trip Relays 0 3 1 - FC111 0
16D2 Acceleration Timer from Start 10 2500 1 s F2 100
16D3 Reserved
...
16DF Reserved
START
INHIBIT
16E0 Start Inhibit Block 0 1 1 - FC103 0
16E1 Thermal Capacity Used Margin 0 25 1 % F1 25
16E2 Reserved
...
16EF Reserved
JOGGING
BLOCK
16F0 Jogging Block 0 1 1 - FC103 0
16F1 Maximum Starts/Hour Permissible 1 5 1 - F1 3
16F2 Time Between Starts 0 500 1 min F1 10
16F3 Reserved
...
16FF Reserved
RESTART
BLOCK
1700 Restart Block 0 1 1 - FC103 0
1701 Restart Block Time 1 50000 1 s F1 1
1702 Reserved
...
177F Reserved
RTD TYPES 1780 Stator RTD Type 0 3 1 - FC120 0
1781 Bearing RTD Type 0 3 1 - FC120 0
1782 Ambient RTD Type 0 3 1 - FC120 0
1783 Other RTD Type 0 3 1 - FC120 0
1784 Reserved
...
178F Reserved
RTD #1 1790 RTD #1 Application 0 4 1 - FC121 1
1791 RTD #1 Alarm 0 2 1 - FC115 0
1792 RTD #1 Alarm Relays 0 6 1 - FC113 0
1793 RTD #1 Alarm Temperature 1 250 1 °C F1 130
1794 RTD #1 Alarm Events 0 1 1 - FC103 0
1795 RTD #1 Trip 0 2 1 - FC115 0
1796 RTD #1 Trip Voting 1 12 1 - FC122 1
1797 RTD #1 Trip Relays 0 3 1 - FC111 0
1798 RTD #1 Trip Temperature 1 250 1 °C F1 155
Table 6–1: 469 MEMORY MAP (Sheet 21 of 43)
GROUP ADDR
(HEX)
DESCRIPTION MIN. MAX. STEP
VALUE
UNITS FORMAT
CODE
DEFAULT
