5.3.10 Setup Event Recorder
PATH: SETPOINTS  S1 745 SETUP  SETUP EVENT RECORDER
These setpoints allow the user to configure the event recorder by enabling/disabling the
event types indicated.
 SETUP EVENT []
RECORDER
PICKUP EVENT:
Enabled
Range: Enabled, Disabled
MESSAGE
OPERATE EVENT:
Enabled
Range: Enabled, Disabled
MESSAGE
DROPOUT EVENT:
Enabled
Range: Enabled, Disabled
MESSAGE
ERROR EVENT:
Enabled
Range: Enabled, Disabled
MESSAGE
OFF EVENT:
Enabled
Range: Enabled, Disabled
MESSAGE
ON EVENT:
Enabled
Range: Enabled, Disabled
