GE 745 - Chapter 5: Setpoints; 5.1 Overview; 5.1.1 Setpoint Message Map

745 TRANSFORMER PROTECTION SYSTEM – INSTRUCTION MANUAL 5–1
745 Transformer Protection
System
Chapter 5: Setpoints
GE
Grid Solutions
Setpoint s
5.1 Overview
5.1.1 Setpoint Message Map
The 745 relay has a considerable number of programmable settings (setpoints) that makes
it extremely flexible. The setpoints have been grouped into a number of pages as shown
below. If using the EnerVista 745 Setup software and not connected to a relay, you may
have to select the File > Properties menu item and set the correct options for your relay.
 SETPOINTS []
S1 745 SETUP
 PASSCODE []
See page 5–25
MESSAGE
 PREFERENCES []
See page 5–25
MESSAGE
 COMMUNICATIONS []
See page 5–26
MESSAGE
 RESETTING []
See page 5–29
MESSAGE
 CLOCK []
See page 5–29
MESSAGE
 DEFAULT []
MESSAGES
See page 5–30
MESSAGE
 SCRATCHPAD []
See page 5–31
MESSAGE
 INSTALLATION []
See page 5–31
MESSAGE
 UPGRADE []
OPTIONS
See page 5–31
MESSAGE
 SETUP EVENT []
RECORDER
See page 5–33
