GE Multilin C30 Controller System 6-3
6 ACTUAL VALUES 6.2 STATUS
6
6.2STATUS 6.2.1 CONTACT INPUTS
PATH: ACTUAL VALUES  STATUS  CONTACT INPUTS
The present status of the contact inputs is shown here. The first line of a message display indicates the ID of the contact
input. For example, ‘Cont Ip 1’ refers to the contact input in terms of the default name-array index. The second line of the
display indicates the logic state of the contact input.
6.2.2 VIRTUAL INPUTS
PATH: ACTUAL VALUES  STATUS  VIRTUAL INPUTS
The present status of the 64 virtual inputs is shown here. The first line of a message display indicates the ID of the virtual
input. For example, ‘Virt Ip 1’ refers to the virtual input in terms of the default name. The second line of the display indicates
the logic state of the virtual input.
6.2.3 REMOTE INPUTS
PATH: ACTUAL VALUES  STATUS  REMOTE INPUTS
The present state of the 64 remote inputs is shown here.
The state displayed will be that of the remote point unless the remote device has been established to be “Offline” in which
case the value shown is the programmed default state for the remote input.
 CONTACT INPUTS

Cont Ip 1
Off
Range: On, Off
MESSAGE
Cont Ip 2
Off
Range: On, Off
↓
MESSAGE
Cont Ip xx
Off
Range: On, Off
 VIRTUAL INPUTS

Virt Ip 1
Off
Range: On, Off
MESSAGE
Virt Ip 2
Off
Range: On, Off
↓
MESSAGE
Virt Ip 64
Off
Range: On, Off
 REMOTE INPUTS

REMOTE INPUT 1
STATUS: Off
Range: On, Off
MESSAGE
REMOTE INPUT 2
STATUS: Off
Range: On, Off
↓
MESSAGE
REMOTE INPUT 64
STATUS: Off
Range: On, Off
