GE Multilin C30 Controller System 5-23
5 SETTINGS 5.2 PRODUCT SETUP
5
2. Set the properties for user-programmable pushbutton 1 by making the following changes in the SETTINGS  PRODUCT
SETUP  USER-PROGRAMMABLE PUSHBUTTONS  USER PUSHBUTTON 1 menu:
PUSHBUTTON 1 FUNCTION: “Self-reset”
PUSHBTN 1 DROP-OUT TIME: “0.20 s”
5.2.4 COMMUNICATIONS
a) MAIN MENU
PATH: SETTINGS  PRODUCT SETUP  COMMUNICATIONS
b) SERIAL PORTS
PATH: SETTINGS  PRODUCT SETUP  COMMUNICATIONS  SERIAL PORTS
The C30 is equipped with two independent serial communication ports. The faceplate RS232 port is intended for local use
and is fixed at 19200 baud and no parity. The rear COM2 port is RS485. The RS485 port has settings for baud rate and par-
ity. It is important that these parameters agree with the settings used on the computer or other equipment that is connected
to these ports. Any of these ports can be connected to a computer running EnerVista UR Setup. This software can down-
load and upload setting files, view measured parameters, and upgrade the relay firmware. A maximum of 32 relays can be
daisy-chained and connected to a DCS, PLC, or computer using the RS485 ports.
 COMMUNICATIONS

 SERIAL PORTS

See below.
MESSAGE
 NETWORK

See page 5–26.
MESSAGE
 ROUTING

See page 5–28.
MESSAGE
 MODBUS PROTOCOL

See page 5–31.
MESSAGE
 DNP PROTOCOL

See page 5–32.
MESSAGE
 DNP / IEC104
 POINT LISTS
See page 5–35.
MESSAGE
 IEC 61850 PROTOCOL

See page 5–36.
MESSAGE
 WEB SERVER
 HTTP PROTOCOL
See page 5–51.
MESSAGE
 TFTP PROTOCOL

See page 5–51.
MESSAGE
 IEC 60870-5-104
 PROTOCOL
See page 5–52.
MESSAGE
 EGD PROTOCOL

See page 5–53.
 SERIAL PORTS

RS485 COM2 BAUD
RATE: 19200
Range: 300, 1200, 2400, 4800, 9600, 14400, 19200,
28800, 33600, 38400, 57600, 115200
MESSAGE
RS485 COM2 PARITY:
None
Range: None, Odd, Even
MESSAGE
RS485 COM2 RESPONSE
MIN TIME: 0 ms
Range: 0 to 1000 ms in steps of 10
