5-128 C30 Controller System GE Multilin
5.6 CONTROL ELEMENTS 5 SETTINGS
5
5.6.7 PID REGULATOR
PATH: SETTINGS  CONTROL ELEMENTS  PID REGULATOR PID 1(4) REGULATOR
PID 1
REGULATOR
PID 1
FUNCTION: Disabled
Range: Enabled, Disabled
MESSAGE
PID 1 SAMPLE TIME:
0.05 s
Range: 0.05 to 30.00 s in steps of 0.01
MESSAGE
PID 1 PROCESS
SIGNAL: Off
Range: Off, any FlexAnalog parameter
MESSAGE
PID 1 SETPOINT
SIGNAL: 0.00
Range: -99999.99 to 99999.99 in steps of 0.01
MESSAGE
PID 1 TRACKING SIGNAL:
Off
Range: Off, any FlexAnalog parameter
MESSAGE
PID 1 PROPORTIONAL
GAIN: 1.00
Range: 0.01 to 100.00 in steps of 0.01
MESSAGE
PID 1 SETPOINT
WEIGHTING: 1.00
Range: 0.01 to 1.00 in steps of 0.01
MESSAGE
PID 1 INTEG. TIME
CONST.: 1.00 sec
Range: 0.00 to 600.00 s in steps of 0.01
MESSAGE
PID 1 ANTIWINDUP:
Disabled
Range: Enabled, Disabled
MESSAGE
PID 1 AW TIME CONST.:
1.00 sec
Range: 0.00 to 600.00 s in steps of 0.01
MESSAGE
PID 1 DERIV. TIME
CONST.: 1.00 s
Range: 0.00 to 600.00 s in steps of 0.01
MESSAGE
PID 1 DERIVATIVE
LIMIT: 10
Range: 1 to 20 in steps of 1
MESSAGE
PID 1 MAX:
10
Range: -10000 to 10000 in steps of 1
MESSAGE
PID 1 MIN:
10
Range: -10000 to 10000 in steps of 1
MESSAGE
PID 1 Tmin:
500 ms
Range: 100 to 1000 ms in steps of 1
MESSAGE
PID 1 DEAD TIME:
1.00 sec
Range: 1 to 20 s in steps of 1
MESSAGE
PID 1 BLK:
Off
Range: FlexLogic operand
MESSAGE
PID 1
TARGET: Self-reset
Range: Self-reset, Latched, Disabled
MESSAGE
PID 1
EVENTS: Disabled
Range: Enabled, Disabled
